FLIRCM82USERMANUALDocumentIdentifier:CM82‐en‐US_AD



Figure5.1Correctandincorrectsetup



1. Ensurethattheprobeleadsaredisconnectedfromthemeter.

2. SetthefunctionswitchtotheAposition.

3. TomanuallyselectAC,DC,orAC+DCmeasurement,pressthe MODEbuttonrepeatedly.

Refertosection5.2Auto/Manualselectmode.

4. Tomanuallyselectthemeasurementrange(scale),presstheRANGEbuttonrepeatedly.

Refertosection5.3Auto/Manualrangemode.

5. Pressthetriggertoopentheclampjaws.Fullyencloseoneconductor—refertoFigure5.1.

Foroptimumresults,centertheconductorinthejaws.

6. Readthecurrentvalueonthedisplay.



5.6.3ExtendedFunctionalityModes

Inadditiontothebasicvoltageandcurrentmeasurements,themetercanbesettodifferent

modesforextendedfunctionality.

5.6.3.1SelectingModes

Themodeiconsapplicablefortheselectedmeasurementtypearedisplayedinthelower

partofthedisplay.Whenamodeisenabled,theiconisframed.



Figure5.2Modeicons(ACvoltagemeasurements):Peakmode/Silentmodeareenabled

Thenavigationbuttonsareusedtoselectamodeiconandtoenable/disableamode:

7. UsetheLEFTandRIGHTnavigationbuttonstonavigatetoamodeicon.Thecurrently

selectediconwillflash.

PresstheOKbuttontoenable/disabletheselected(flashing)mode.



5.6.3.2PeakMode


