Technical data26
26.23 FLIR T10xx SC kit
P/N: 72500-0002
Rev.: 36742
General description
The FLIR T10xx SC kit is intended for R&D usage and development purposes. The kit includes a high-
speed interface (HSI) box, which enables streaming of fully radiometric and uncompressed video from
a FLIR T10xx series camera to a PC running the FLIR ResearchIR Max software.
Communication
Interfaces
• USB 3 Vision
• Digital I/O
• Proprietary FLIR interface
Image streaming
• Up to 120 Hz full frame
• Up to 240 Hz by windowing
Image formats
• Unfiltred, uncompressed 14 bit radiometric
raw data
• Lossless, maximal sensitivity
Electronics and data rate
Video streaming
Windowing
• 30 Hz: 1024 × 768 (full image height)
• Based on 30 Hz: 120 Hz windowing 1024 ×
192 (¼ of full image height), for range –40 to
+150°C (–40 to +302°F)
• 120 Hz: 1024 × 768 (full image height)
• Based on 120 Hz: 240 Hz windowing 1024 ×
384 (½ of full image height), for range 0 to
+650°C (+32 to +1202°F) and range +300 to
+2000°C (+572 to +3632°F)
Power system
Power, HSI box Powered from PC via USB 3
Physical data
Weight, HSI box 0.405 kg (0.893 lb.)
Weight, USB cable 0.135 kg (0.298 lb.)
Size (L × W × H), HSI box 125 × 72.4× 56.7 mm (4.92 × 2.85 × 2.23 in.)
Mounting, HSI box Tripod mount, velcro straps
Shipping information
Packaging, type Cardboard box
List of contents
• High-speed interface
• Hard transport case
• USB cable (USB 3), 3 m (10 ft.)
• Digital I/O connector
• FLIR ResearchIR Max license card
• Printed documentation
Packaging, weight 2.1 kg (4.6 lb.)
Packaging, size 303 × 206 × 128 mm (11.9 × 18.1 × 5.0 in.)
EAN-13 7332558011041
#T559954; r. AP/42311/42335; en-US
