Using the high-speed interface (HSI)
8
9. Object of study.
8.3 Quick start guide
Follow this procedure:
1. Go to http://support.flir.com/rir4 and download FLIR ResearchIR Max.
2. Install FLIR ResearchIR Max.
3. Start FLIR ResearchIR Max.
When asked for the license key, enter the license key that is printed on the FLIR Re-
searchIR Max download card. The card is included with the HSI box.
4. Connect the HSI box to the computer using the provided USB 3 cable.
5. Connect the camera to the HSI box using the integrated high-speed interface cable.
6. Start the camera. This displays a start-up dialog box in FLIR ResearchIR Max. If the
start-up dialog box is not displayed, go to View > Startup Dialog.
7. In the start-up dialog box, click the camera you want to connect to.
For more information about the installation and connection processes, see the FLIR Re-
searchIR Max manual.
8.4 HSI box indicator LED
Indicator LED status Explanation
The indicator LED displays a continuous blue light. The HSI box is operational, and video data is now
continuously streamed to the computer.
The indicator LED displays a flashing blue light,
with a period time of about 1 second.
The HSI box is connected to the computer, but
the link between the camera and the box is not up.
Either the cable to the camera is not correctly con-
nected or there is another error on the link.
The indicator LED displays a continuous blue light
with short interrupts.
Each interrupt in the continuos light indicates a bit
error in the video data stream.
8.5 Digital I/O
For information about the optional Digital I/O connection, see sections 28 Digital I/O pin
configuration, page 195 and 29 Digital I/O connection diagram, page 196.
#T559954; r. AP/42311/42335; en-US
17
