FLIR T10 Series

Working with image modes16
Image mode Image
Picture in picture
Digital camera
16.3 Selecting the image mode
Follow this procedure:
1. Push the joystick to display the menu system.
2. Use the joystick to go to
(Image mode).
3. Push the joystick to display a submenu.
4. Use the joystick to go to one of the image modes:
•
(Thermal MSX)
•
(Thermal)
•
(Picture in picture)
•
(Digital camera)
Note If the *.csq video format is selected (Settings > Save options & storage > Vid-
eo compression ) and the recording mode Video is selected, it will only be possible
to select the image mode Thermal.
5. Push the joystick confirm.
6. If Picture in picture mode is selected, you can at this point move and resize the infra-
red image frame using the touch screen.
#T559954; r. AP/42311/42335; en-US
56
