FLIR T10 Series

Camera parts
10
10.1 View from the right
10.1.1 Figure
10.1.2 Explanation
1. Knob to change the dioptric correction for the viewfinder.
2. Hand strap.
3. Digital zoom button.
4. Save button (push fully down).
Note The infrared camera can be configured to autofocus when you push the Save
button half-way down. To enable the autofocus function of the Save button, select
(Settings) > Save options & storage > Save button half-press = Autofocus.
10.2 View from the left
10.2.1 Figure
10.2.2 Explanation
1. Digital camera.
2. Camera lamp.
