Annotating images19
The camera has a number of default table templates. You can also import your own table
templates from FLIR Tools/Tools+—refer to the FLIR Tools/Tools+ user’s manual. The
templates are stored on the memory card.
19.3.2 Procedure
Follow this procedure:
1. Open the image in the image archive.
2. Push the joystick. This displays a context menu.
3. Select
(Add table) and push the joystick.
4. Select
(Add table contents) and push the joystick. This displays the default table
template that ships with the camera.
Note You can select another template by first selecting
(Select default
template).
5. For each row in the table, do the following:
• Push the joystick. This displays the predefined values.
• Move the joystick up/down to select a predefined value. Push the joystick to
confirm.
• Instead of selecting a predefined value, you can select the keyboard
and enter
other text by touching the screen.
6. When completed, select Save & Exit at the bottom of the table. Push the joystick to
confirm.
19.4 Adding a voice annotation
19.4.1 General
A voice annotation is an audio recording that is saved to the infrared image file. The re-
cording can be played back in the camera, and in image analysis and reporting software
from FLIR Systems.
The voice annotation is recorded using a Bluetooth headset. For information on how to
pair a headset with the camera, see section 23 Pairing Bluetooth devices, page 76.
#T559954; r. AP/42311/42335; en-US
70
