Handling the camera13
13.4 Adjusting the viewfinder’s dioptric
correction (sharpness)
13.4.1 Figure
CAUTION
Applicability: Cameras with a viewfinder.
Make sure that the beams from the intensive energy sources do not go into the viewfinder. The beams
can cause damage to the camera. This includes the devices that emit laser radiation, or the sun.
13.4.2 Procedure
Follow this procedure:
1. Push the button to switch from touch-screen LCD mode to viewfinder mode.
2. To adjust the viewfinder’s dioptric correction, look through the viewfinder and rotate
the adjustment knob clockwise or counter-clockwise for the best sharpness.
Note
• Maximum dioptric correction: +2.
• Minimum dioptric correction: –2.
#T559954; r. AP/42311/42335; en-US
29
