Page 29CWT S5 Installation & Maintenance ManualIssue 5
Product description
Door inside
Figure 21, Door interior
1. Display unit
2. Warning indicator.
3. Wake-up button
4. Bar-code reader
5. Card reader with contactless reader and
pin-pad
6. Coin return cup
7. Ticket outlet
8. Coin detection sensor
Inside of the cabinet
