Page 46CWT S5 Installation & Maintenance ManualIssue 5
Installation
5.2 Installing the terminal
Due to its heavy weight the terminal is usually transported in two pieces to the
installation site where the pedestal is secured to a concrete base or floor before
the cabinet is mounted on top of the pedestal.
Provided there is an appropriate lifting device or a hand cart at hand, the entire
terminal can be installed as a complete unit.
5.2.1
Mounting the pedestal in its foundation
WARNING:
Lifting the pedestal, the cabinet, or the complete terminal, requires two or three
persons due to the heavy weights.
Before the terminal has been secured to the foundation, there is a risk of the
terminal tipping forward, especially when you open the cabinet door.
·
Place the terminal at the site that has been prepared. see Site
preparations for instructions.
·
Fasten the terminal with 4–8 expansion screws or mount the terminal on an
existing base anchor or similar using the appropriate nuts and washers.
Important:
The function of the coin system and the water drainage (door shelf) may be
interrupted if the terminal leans more than a couple of degrees in any direction.
5.2.2
Mounting the cabinet on top of the pedestal
·
Remove the 4 screws fixing the protective plate at the top of the pedestal.
The screws will be used to secure the cabinet onto the pedestal.
·
Carefully place the cabinet on top of the pedestal.
·
Secure the cabinet to the pedestal with the four screws as mentioned above.
·
Thread the unconnected cables up into the cabinet or down into the
pedestal.
5.2.3
Installing the battery
Place the battery on the floor in the bottom of the pedestal.
Important:
The RED coloured lead must be attached to the POSITIVE pole on the battery.
Connecting with wrong polarity will blow one or more fuses on the CPU board and
will result in unrepairable damages to the Main board.
in a mains-powered terminal
Connect the battery to the 12 V distribution panel on the battery charger to the
connector marked
41
