Maintenance
· Clean the surface
· Add the new tape to the new window and place it in the door.
· Mount the new scanner in reverse order
· The cable is on the main board connected to connector J35
7.7 Cabinet & pedestal
Cleaning
Clean the exterior of the metal cabinet surfaces using petroleum spirits (white
spirit) or a mild cleaning solution.
· See Section Solar panel, cleaning , regarding cleaning of the solar panel.
Lubrication
Lubricate the lock cylinders with Kaba-Clean spray or an equivalent lubricant.
The autumn is a good time to do this.
Check the friction in the hinge pins of the doors. Lubricate if necessary, with a
lubricant such as Moebius 8200.
Caution:
Thin lubricants such as CRC 556 must not be used.
7.7.1
E-lock replacement
Removal
1. Disconnect the cables from the E-lock.
2. Remove four nuts and remove the E-lock. A small box spanner (10 mm) is
required to remove the lower E-lock due to limited space.
Assembly
Ensure that the dowel pin (see arrow) mates with the locking latches.
