16
D3 Digital Positioner model code
A=
Model no
D3X Digital positioner with display and indicator, General purpose
D3Z Digital positioner with display and indicator, General purpose, Direct mount to FlowAct
D3I Digital positioner with display and indicator, Intrinsically safe ATEX
D3Y Digital positioner with display and indicator, Intrinsically safe ATEX, Direct mount to FlowAct
D3E Digital positioner with display, no indicator, Explosion proof ATEX, CSA/FM
D3F Digital positioner with display, Explosion proof ATEX, FM, IEC Direct mount to FlowAct
B=
Connections
G 1/4” G air, M20 x 1,5 electrical
N 1/4” NPT air, 1/2” NPT electrical
M 1/4” NPT air, M20 x 1,5 electrical
C=
Surface treatment
U Powder epoxy
D=
Function
S Single acting
L Single acting, Fail Freeze
P Single acting, Fail freeze remote mounted
M Single acting, remote mounted
D Double acting acting
H Double acting high-flow (A=D3X only)
T Double acting high-flow remote (A=D3X only)
K Double acting Fail Freeze function
Q Double acting Fail freeze remote mounted
R Double acting Remote mounted
E=
Spindle
23 Rotary VDI/VDE 3845
39 D type with thread/nut for Linear actuators
09 Double D type & adator spindle for 01/02/06/21/26/30/36/41
BA BASF special unit with, Spindel 39 With adapter
F= Cover and Indicator (No indicator on D3E, D3F)
PVA Black PMV, 90 deg, Arrow indicator
PVB Black, Extended travel, 270 deg Arrow indicator
FSW White cover, Flowserve, 90 deg, Arrow indicator
FSY Yellow cover, Flowserve, 90 deg, Arrow indicator
WCA Worcester Controls, Arrow indicator
G=
Sensors/Temperature/seals
Z No pressure sensors, NBR -30 to 80 deg C (-40 deg C for non-certified versions)
Y On Board pressure sensors, NBR -30 to 80 deg C (-40 deg C for non-certified versions)
H= Input signal/Protocol
4 4-20 mA
5 HART, 4-20 mA
P Profibus PA
D Profibus DP
F Foundation Fieldbus
I=
Feedback option (Limitations for D3E)
X No feedback option
T* Plug in 4-20 mA transmitter only + Alarm module
S* Limit switches MEC + 4-20 mA + Alarm
N* Limit sensors NAM + 4-20 mA + Alarm
P* Limit switches PXY + 4-20 mA + Alarm
4* Slot type Namur sensor, P+F SJ2 S1N + Alarm
5* Slot type Namur sensor, P+F SJ2 SN + Alarm
6* Slot type Namur sensor, P+F SJ2N + Alarm
J=
Accessories
X No accessories
M Gauge block For D3X, D3I only, For D3E (default) Gauge ports D3E, D3F (default)
1 Gauge block incl 1 gauge included stainless/brass
2 Gauge blocks incl 2 gauges included stainless/brass
3 Gauge blocks incl 2 gauges included stainless/brass
A A A B C - D E E F F F - G H I J
*Not for D3E, D3F
PMV D3 Digital Positioner FCD PMENIM0001-06 A5 09/16
