19
BASIC MENU
READ
BASIC MENU
MAN/AUTO
BASIC MENU
CALIBRA
TE
BASIC MENU
SHIFT MENU
FULL MENU
READ
FULL MENU
MAN/AUTO
FULL MENU
CALIBRA
TE
FULL MENU
SHIFT MENU
FULL MENU
ST
A
TUS
FULL MENU
SETUP
FULL MENU
TUNING
FULL MENU
ALARMS
FULL MENU
F
ACT SET
Menu system
The menus are described
on the following pages.
PMV D3 Digital Positioner FCD PMENIM0001-06 A5 09/16
18
20
Table of Contents
Default Chapter
2
Table of Contents
2
1 Introduction
3
Safety Instruction
3
2 Storage
5
General
5
Storage Indoors
5
Storage Outdoors or for a Longer Period
5
Storage in a Warm Place
5
3 Design
6
4 Variants
7
5 Function
8
6 Installation
9
Removal of Covers
9
Tubing
9
Air Supply Requirements
9
Mounting
10
Connections
11
Single Action Positioner, Direct Function
12
Double Action Positioner, Direct Function
12
Electrical Connections
13
Signs
15
D3 Digital Positioner Model Code
16
7 Control
17
Menus and Pushbuttons
17
Other Functions
17
Menu Indicator
18
Menus
18
Changing Parameter Values
18
Menu System
19
First Start (with Calibration Sequence)
20
ISA100 Wireless Function (WL)
23
Expert Calibration
33
8 Maintenance/Service
35
Disassembling PMV D3
35
Silencer
37
Potentiometer
38
Transmitter Boards
38
Disassembling PMV D3 Ex
43
Filter Change
44
9 Trouble Shooting
45
10 Technical Data
46
11 Dimensions
48
12 Spare Parts
51
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Flowserve PMV D3 and is the answer not in the manual?
Ask a question
