Rotation angle min. 30° max 100°, option 270°
Stroke 5-130 mm (0.2” to 5.1”)
Input signal 4-20 mA DC
Air supply 2-7 bar (30-105 psi)
DIN/ISO 8573-1 3.2.3
Free from oil, water and moisture.
Air delivery 350 nl/min (13.8 scfm)
Air consumption <0.3 nl/min (0.01 scfm)
Air connections ¼” G or NPT
Cable entry 3 x M20x1,5 or ½” NPT (D3E 2x)
Electrical connections Screw terminals 2.5 mm
2
/AWG14
Linearity <1%
Repeatability <0.5%
Hysteresis <0.4%
Dead band 0.2-10% adjustable
Display Graphic, view area 15 x 41mm (0.6 x 1.6”)
UI 5 push buttons
CE directives 93/68EEC, 89/336/EEC, 92 /31/EEC
EMC EN 50 081-2, EN 50 082-2
Voltage drop, without HART < 8.0 V => resistance 400 Ω
Voltage drop, with HART < 9.4 V => resistance 470 Ω
Vibrations <1% up to 10 g at frequency 10-500 Hz
Enclosure IP66/NEMA 4X
Material Die-cast Aluminum/Stainless Steel
A2/A4 fasteners
Surface treatment Powder epoxy (Aluminum version only)
Temperature range –30 to +80 °C / –22 to 176 °F
(-40 °C / – 40 °F for non-certified versions)
Weight PMV D3X, 1.4 kg (3 lbs).
PMV D3E, 3 kg (6.6 lbs)
PMV D3E Stainless Steel, 6 kg (13.2 lbs)
Alarm output Transistor Ri 1 KΩ
Alarm Supply Voltage 8-28 V DC
Mounting position Any
10. Technical data
