37
Valve block
Turn off the air and electric power
supply before starting any work.
• Remove the four screws and lift out the
valve block
Note: Do not disassemble the valve block
• When installing the valve block — torque
the four screws cross-wise to 2,5 Nm
and seal with Loctite
®
222.
Silencer
A silencer, L (option) can be mounted under
the plate M on the PMV D3. Contact PMV.
M L
I
