48
11. Dimensions
201 / 7.9”
102 / 4”
82 / 3.2”
76 / 3”
35.4 / 1.4”
35.4 / 1.4”
51 / 2”
M6 / (4x)
PMV D3 Digital Positioner FCD PMENIM0001-06 A5 09/16
