Flowserve PMV D3 User Manual

54
No Part no Description
3 D3E-SP4 Internal cover incl. screws
5 D3-SP1 See D3 page 53
5 D3-SP1-PS See D3 page 53
7 3E-SP8 Potentiometer complete incl. spring, holder, cable
8 3-AS23 S23 Shaft complete incl. gearwheel, friction clutch, spring
8 3-AS39 S39 Shaft complete incl. gearwheel, friction clutch, spring
8 3-AS09 S09 Shaft complete incl. gearwheel, friction clutch, spring
9 3E-SP80X PCB Mother board
9 3E-SP80XT PCB Mother board, 4-20mA transmitter
9 3E-SP80H PCB Mother board HART
9 3E-SP80HT PCB Mother board, HART 4-20mA transmitter
10 3-SP84 See D3 page 53
11 3-SP37HR See D3 page 53
12 3E-SP83 PCB Terminals
13 D3E-SP/SCREW Kit, bag with screws
14 D3E-SP/SEAL Kit, bag with O-rings, seals
Explosion Proof housing
PMV D3 Digital Positioner FCD PMENIM0001-06 A5 09/16
