Fluke 726 User Manual

Specifications
63
RTD Accuracy (Read and Source) (ITS-90)
Range Minimum Maximum Accuracy
Ni120 (672) -80.00 260.00 0.15
-200.00 100.00 0.15
100.00 300.00 0.25
300.00 600.00 0.35
Pt100 (385)
600.00 800.00 0.45
-200.00 100.00 0.15
100.00 300.00 0.25
Pt100 (3926)
300.00 630.00 0.35
-200.00 100.00 0.15
100.00 300.00 0.25
Pt100 (3916)
300.00 630.00 0.35
-200.00 100.00 0.75
100.00 300.00 0.85
Pt200 (385)
300.00 630.00 0.95
-200.00 100.00 0.35
100.00 300.00 0.45
Pt500 (385)
300.00 630.00 0.55
-200.00 100.00 0.15
100.00 300.00 0.25
Pt1000 (385)
300.00 630.00 0.35
CU10 -10.00 250.00 1.8
Notes: Read Accuracy is based on 4-wire input. For 3-wire input, add ± 0.05 e assuming all three RTD leads are matched.
Source Accuracy is based on 0.5 to 3.0 mA excitation current (0.1 mA for pt1000 range)
Multifunction Process Calibrator

Fluke 726 Specifications

General

Auto-ramp function	Yes
Measuring parameters	Current, Frequency, Resistance, Temperature, Voltage
Frequency source accuracy	0.5 %
Frequency measurement accuracy	0.05 %
DC current measurement accuracy	0.01 %
DC voltage measurement accuracy	0.025 %
Resistance measurement accuracy	0.015 %
Product color	Black, Yellow

Weight and Dimensions

Depth	47 mm
Width	96 mm
Height	200 mm
Weight	650 g
