Fluke 726 User Manual

Multifunction Process Calibrator
Storing and Recalling Data
43
Recall a Setup
To recall a setup:
1. Push S twice. The right side of the display
changes to show RECL SETUP and RECALL DATA.
2. Push S again to RECL SETUP.
3. Push Z to select the desired memory location (at the
top of the LCD).
4. Push S to recall the setup from the proper
memory location.
Storing and Recalling Data
Up to 40 data samples can be stored in a nonvolatile
memory to be recalled for later use. A low battery
condition or a battery change does not jeopardize the
stored settings.
Storing Data
To store measurement data, use the following procedure,
refer to Figure 19.
1. Take the desired measurement.
2. Push S. The right side of the display changes to
show SAVE SETUP and SAVE DATA.
3. Press W to select SAVE DATA.
4. Push S again. The open data point (bottom right
of the display) flashes.
5. Use Y and Z to change the data point location (1-8).
6. Push S to store the measurement and return the
unit to the measurement mode. Figure 19 shows a
reading stored in memory location 3, data point 1.

Fluke 726 Specifications

General

Auto-ramp function	Yes
Measuring parameters	Current, Frequency, Resistance, Temperature, Voltage
Frequency source accuracy	0.5 %
Frequency measurement accuracy	0.05 %
DC current measurement accuracy	0.01 %
DC voltage measurement accuracy	0.025 %
Resistance measurement accuracy	0.015 %
Product color	Black, Yellow

Weight and Dimensions

Depth	47 mm
Width	96 mm
Height	200 mm
Weight	650 g
