Fluke 726 User Manual

Multifunction Process Calibrator
Configuration Menus
15
Shut Down Mode
The Calibrator comes with a shut down mode set for 30
minutes (displayed for about 1 second when the
Calibrator is initially turned on). When shut down mode is
enabled, the Calibrator automatically shuts down after
the elapsed time from when the last key was pressed.
1. Press C until SHUT DOWN appears on the
display.
2. Use X and W to increase or decrease the time.
3. Press S to save the setting.
CJC
Cold Junction Compensation (CJC) is a value for the cold
end of a thermocouple at the Meter’s end.
1. Press C until SELECT CJC appears on the
display.
2. Use
Y and Z to select ON or OFF.
3. Press S to save the setting.
Celcius and Fahrenheit ( ° C and ° F)
1. Press C until SELECT UNIT °C (or °F) appears
on the display.
2. Use X and W to select °C or °F.
3. Press S to save the setting.
Frequency Pulse Output Voltage
1. Press C until FREQ OUTPUT V Adjust appears
on the display.
2. Use X, W,
Y and Z to adjust the frequency pulse
output voltage from 1 to 20 V.
3. Press S to save the setting.
Pulse Output Frequency
1. Press C until PULSE OUTPUT Hz FREQ Adjust
appears on the display.
2. Use X, W,
Y and Z to adjust the pulse output
frequency from 2 CPM to 15 kHz.
3. Press S to save the setting.

Fluke 726 Specifications

General

Auto-ramp function	Yes
Measuring parameters	Current, Frequency, Resistance, Temperature, Voltage
Frequency source accuracy	0.5 %
Frequency measurement accuracy	0.05 %
DC current measurement accuracy	0.01 %
DC voltage measurement accuracy	0.025 %
Resistance measurement accuracy	0.015 %
Product color	Black, Yellow

Weight and Dimensions

Depth	47 mm
Width	96 mm
Height	200 mm
Weight	650 g
