Pos Description Part No. P
R306 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R307 RESISTOR 47 ohm 1% 0.1W 100PPM 0805 5322 117 12505 S
R309 RESISTOR 47 ohm 1% 0.1W 100PPM 0805 5322 117 12505 S
R31 POTENTIOMETER 100 kohm 3304X-1-104 5322 101 10841 S
R310 RESISTOR 27 ohm 1% 0.1W 100PPM 0805 4031 002 27090 S
R311 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R312 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R313 RESISTOR 56 ohm 1% .125W 100PPM 1206 4822 051 10569 S
R314 RESISTOR 120 ohm 1% 0.1W 100PPM 0805 5322 117 12506 S
R315 RESISTOR 820 ohm 1% .125W 100PPM 1206 5322 116 82264 S
R316 RESISTOR 2.20 kohm 1% .125W 100PPM 1206 4822 051 52202 S
R317 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R318 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R319 RESISTOR 56 ohm 1% .125W 100PPM 1206 4822 051 10569 S
R32 RESISTOR 470 kohm 1% .125W 100PPM 1206 5322 116 80447 S
R320 RESISTOR 56 ohm 1% .125W 100PPM 1206 4822 051 10569 S
R321 RESISTOR 10.0 ohm 1% 0.125W 100PPM 1206 4822 051 10109 S
R322 RESISTOR 10.0 ohm 1% 0.125W 100PPM 1206 4822 051 10109 S
R323 RESISTOR 47 ohm 1% 0.1W 100PPM 0805 5322 117 12505 S
R325 RESISTOR 47 ohm 1% 0.1W 100PPM 0805 5322 117 12505 S
R326 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R327 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R328 RESISTOR 27 ohm 1% 0.1W 100PPM 0805 4031 002 27090 S
R329 RESISTOR 120 ohm 1% 0.1W 100PPM 0805 5322 117 12506 S
R33 POTENTIOMETER 10 kohm 3304X-1-103 5322 100 11143 S
R330 RESISTOR 47 ohm 1% 0.1W 100PPM 0805 5322 117 12505 S
R331 RESISTOR 47 ohm 1% 0.1W 100PPM 0805 5322 117 12505 S
R34 RESISTOR 18.0 kohm 1% .125W 100PPM 1206 5322 117 10034 S
R35 RESISTOR 470 ohm 1% .125W 100PPM 1206 4822 051 54701 S
R36 RESISTOR 470 ohm 1% .125W 100PPM 1206 4822 051 54701 S
R37 RESISTOR 1.50 kohm 1% 0.125W 100PPM 1206 4822 051 51502 S
R38 RESISTOR 1.00 kohm 1% 0.125W 100PPM 1206 4822 051 51002 S
R39 RESISTOR 10 MOHM 10% 0.25W RC-01 1206 4822 051 10106 S
R4 RESISTOR 220 kohm 1% .125W 100PPM 1206 4822 051 52204 S
R40 RESISTOR 47 ohm 1% 0.1W 100PPM 0805 5322 117 12505 S
R41 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R42 RESISTOR 15.0 ohm 1% .125W 100PPM 1206 4822 051 10159 S
R43 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R44 RESISTOR 47 ohm 1% .125W 100PPM 1206 5322 116 80448 S
R45 RESISTOR 47 ohm 1% 0.1W 100PPM 0805 5322 117 12505 S
R46 RESISTOR 150 ohm 1% 0.125W 100PPM 1206 4822 051 51501 S
R47 RESISTOR 150 ohm 1% 0.125W 100PPM 1206 4822 051 51501 S
R48 RESISTOR 82 ohm 1% .125W 100PPM 1206 4822 051 10829 S
R49 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R5 RESISTOR 220 kohm 1% .125W 100PPM 1206 4822 051 52204 S
R50 RESISTOR 8.2 ohm 10% 0.25W RC-01 1206 4822 051 10828 S
R51 RESISTOR 2.70 kohm 1% .125W 100PPM 1206 4822 051 52702 S
R53 RESISTOR 2.20 kohm 1% .125W 100PPM 1206 4822 051 52202 S
R54 RESISTOR 560 ohm 1% .125W 100PPM 1206 4822 051 10561 S
R55 RESISTOR 560 ohm 1% .125W 100PPM 1206 4822 051 10561 S
R56 RESISTOR 390 ohm 1% .125W 100PPM 1206 4822 051 53901 S
R57 RESISTOR 15.0 kohm 1% .125W 100PPM 1206 5322 116 82261 S
R58 RESISTOR 120 ohm 1% 0.125W 100PPM 1206 4822 051 10121 S
R6 RESISTOR 47 ohm 1% .125W 100PPM 1206 5322 116 80448 S
R60 RESISTOR 4.70 kohm 1% .125W 100PPM 1206 4822 051 54702 S
R61 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R63 RESISTOR 6.80 kohm 1% .125W 100PPM 1206 4822 051 10682 S
R64 RESISTOR 1.00 kohm 1% 0.125W 100PPM 1206 4822 051 51002 S
R65 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R66 RESISTOR 4.70 kohm 1% .125W 100PPM 1206 4822 051 54702 S
R67 RESISTOR 2.20 kohm 1% .125W 100PPM 1206 4822 051 52202 S
R69 POTENTIOMETER 100 kohm 3304X-1-104 5322 101 10841 S
R7 RESISTOR 120 ohm 1% 0.125W 100PPM 1206 4822 051 10121 S
R70 POTENTIOMETER 100 kohm 3304X-1-104 5322 101 10841 S
Pos Description Part No. P
R71 RESISTOR 100 kohm 1% 0.125W 100PPM 1206 4822 051 51004 S
R72 RESISTOR 100 kohm 1% 0.125W 100PPM 1206 4822 051 51004 S
R73 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R74 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R75 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R76 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R77 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R78 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R79 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R8 RESISTOR 120 ohm 1% 0.125W 100PPM 1206 4822 051 10121 S
R80 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R81 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R82 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R83 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R84 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R85 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R86 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R87 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R88 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R89 RESISTOR 68 ohm 1% .125W 100PPM 1206 4822 051 10689 S
R9 RESISTOR 120 ohm 1% 0.125W 100PPM 1206 4822 051 10121 S
R90 RESISTOR 68 ohm 1% .125W 100PPM 1206 4822 051 10689 S
R91 POTENTIOMETER 100ohm CVR-4A-101 5322 101 10989 S
R92 RESISTOR 8.20 kohm 1% .125W 100PPM 1206 4822 051 10822 S
R93 RESISTOR 47 ohm 1% 0.1W 100PPM 0805 5322 117 12505 S
R94 RESISTOR 47 ohm 1% 0.1W 100PPM 0805 5322 117 12505 S
R95 RESISTOR 3.30 kohm 1% .125W 100PPM 1206 4822 051 53302 S
R96 RESISTOR 1.80 kohm 1% .125W 100PPM 1206 4822 051 10182 S
R98 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R99 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
U1 IC-OP AMP CA3140AM CA3140 AM BIMOS SO8 9322 114 39682 R
U10 IC-ANA TL7705BCD SMD LOW VOLT DETECT 5322 209 90426 R
U11 IC MICROP N80C196KB10 5322 209 52203 R
U12 IC-PROM 24LC16B 16kBIT I2C SMD SO8 9322 186 14682 P
U13 IC PC74HC574T SO20 4822 209 60451 S
U14 IC PC74HC573T SO20 5322 209 60424 S
U15 IC PC74HC02T SO-14 5322 209 71563 S
U16 IC PC74HC573T SO20 5322 209 60424 S
U17 IC PC74HC573T SO20 5322 209 60424 S
U18 IC PC74HC21T SO14 5322 209 60437 S
U19 IC PC74HC00T SO14 5322 209 71802 S
U2 IC PC74HC574T SO20 4822 209 60451 S
U20 IC PC74HC138T SO16 5322 209 73178 S
U21 IC NE532D DUAL SO-8 5322 209 71553 R
U22 IC-SRAM TC55257DFL-85L SOP28 32Kx8 9322 106 65682 R
U23 IC-PROM PM6685 27C512 5322 209 31776 P
U23 IC SOCKET 32 POL P/N 213-032-602 5322 255 41141 S
U24 IC PC74HC32T SO14 4822 209 63475 S
U25 IC PC74HC32T SO14 4822 209 63475 S
U26 IC-CMOS 74HC10 SO14 SO-14 9337 142 80653 S
U27 IC-DIG ECL 100331QC 3XDFLIP-FLOP PCC28 5322 209 33604 S
U28 IC-BUS TRANSCEIV 75ALS176D SO-8 SMD 5322 209 33171 R
U29 IC-ASIC 5322 209 90513 R
U3 IC PC74HC4353T SO20 4822 209 62805 S
U30 IC PC74HC00T SO14 5322 209 71802 S
U31 IC-OMV ADC 10BIT ADC1061C1WM SO20 9322 187 55682 R
U32 IC PC74HC573T SO20 5322 209 60424 S
U34 IC PC74HC00T SO14 5322 209 71802 S
U35 IC-OMV ADC 10BIT ADC1061C1WM SO20 9322 187 55682 R
U36 IC PC74HC573T SO20 5322 209 60424 S
U38 IC NE532D DUAL SO-8 5322 209 71553 S
U39 POWER MODULE 5322 693 22828 R
U4 IC 8 BIT PM7528HPC PLCC20 4822 209 62803 S
U40 IC HEF4013BT SO14 5322 209 14477 S
7-10 Replacement Parts, Main Board
