Main Board
Pos Description Part No. P
227 CHOKE 4S2 3.5X6MM BANDAD 80ohm at 100MHz 5322 157 61928 S
B1 CRYSTAL 12.000 MHz SMD MA-406 2422 543 01353 P
B2 CRYSTAL 10 MHz HC-49U/13 5322 242 82118 P
C1 CAPACITOR-TRIM 0.5-2 pF 300V 5322 124 80335 S
C10 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C100 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C101 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C102 CAPACITOR 33 pF 5% 50V NP0 0805 2222 861 15339 S
C103 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C104 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C105 CAPACITOR 6.80 UF 20% 16V 6.0X3.2 MOLD 5322 124 10687 R
C106 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C107 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C108 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C109 CAPACITOR 22 pF 5% 50V NP0 0805 5322 122 32658 S
C11 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C110 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C111 CAPACITOR 15 UF 20%6.3V 6.0X3.2 MOLD 5322 124 11418 S
C112 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C113 CAPACITOR 82 pF 5% 50V NP0 0805 2222 861 15829 S
C114 CAPACITOR 100 pF 5% 50V NP0 0805 2222 861 15101 S
C115 CAPACITOR-TRIM 3-10 pF TZBX4Z100BB110 5322 125 50306 R
C116 CAPACITOR 47 pF 5% 50V NP0 0805 2222 861 15479 S
C117 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C118 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C119 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C12 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C120 CAPACITOR 10 pF 5% 50V NP0 0805 2222 861 15109 S
C121 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C122 CAPACITOR 680 pF 20% 63V NP0 1206 4822 126 12075 S
C123 CAPACITOR 47 pF 5% 50V NP0 0805 2222 861 15479 S
C124 CAPACITOR 100nF 20% 25V X7R 0805 5322 126 13638 S
C125 CAPACITOR 2.20 UF 20% 6.3V 3.2X1.6 MOLD 5322 124 10685 S
C126 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C127 CAPACITOR 1 nF 20% 50V X7R 0805 5322 122 34123 S
C128 CAPACITOR 82 pF 5% 50V NP0 0805 2222 861 15829 S
C129 CAPACITOR 6.8 pF 5% 50V NP0 0805 2222 861 15688 S
C13 CAPACITOR 47 pF 5% 50V NP0 0805 2222 861 15479 S
C130 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C131 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C132 CAPACITOR 2.20 UF 20% 6.3V 3.2X1.6 MOLD 5322 124 10685 S
C133 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C134 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C135 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C136 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S
C138 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C139 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S
C14 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C140 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C141 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C142 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C143 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C145 CAPACITOR 390 pF 5% 50V NP0 0805 4822 122 32636 S
C146 CAPACITOR 10 pF 5% 50V NP0 0805 2222 861 15109 S
C148 CAPACITOR 470 pF 1% 63V NP0 0805 5322 126 14051 S
C149 CAPACITOR 22 pF 5% 50V NP0 0805 5322 122 32658 S
C15 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C150 CAPACITOR 390 pF 5% 50V NP0 0805 4822 122 32636 S
C151 CAPACITOR 10 pF 5% 50V NP0 0805 2222 861 15109 S
C153 CAPACITOR 470 pF 1% 63V NP0 0805 5322 126 14051 S
C154 CAPACITOR 22 pF 5% 50V NP0 0805 5322 122 32658 S
Pos Description Part No. P
C155 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C156 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S
C157 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S
C158 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C159 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C16 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S
C160 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C161 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C162 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C163 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C164 CAPACITOR 2.20 UF 20%6.3V 3.2X1.6 MOLD 5322 124 10685 S
C165 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C166 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S
C167 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C168 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C169 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C17 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C170 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C171 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C172 CAPACITOR 2.20 UF 20% 6.3V 3.2X1.6 MOLD 5322 124 10685 S
C173 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C174 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C175 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C176 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C177 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C178 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C179 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C18 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C180 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C181 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C182 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C183 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C184 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C185 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S
C186 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S
C19 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C2 CAPACITOR-TRIM 2.0-18 pF 300V 2222 809 05217 R
C20 CAPACITOR 1 nF 20% 50V X7R 0805 5322 122 34123 S
C21 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C22 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C23 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C24 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C25 CAPACITOR 10 pF 5% 50V NP0 0805 2222 861 15109 S
C26 CAPACITOR 10 pF 5% 50V NP0 0805 2222 861 15109 S
C27 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C28 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C29 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C3 CAPACITOR 22 nF 10% 200V X7R 1206 5322 126 14081 R
C30 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C31 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C32 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C33 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C34 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C35 CAPACITOR 470 nF 10% 25V X7R 1210 4822 126 12549 S
C36 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C37 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C38 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
C39 CAPACITOR 6.80 UF 20% 16V 6.0X3.2 MOLD 5322 124 10687 R
C4 CAPACITOR 3.3 pF ±0.25pF 50V NP0 0805 2222 861 15338 S
C40 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S
C41 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S
7-6 Replacement Parts, Main Board
