Pos Description Part No. P

C42 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C43 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C44 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C45 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S

C46 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C47 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S

C48 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C49 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C5 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C50 CAPACITOR 2.20 UF 20% 6.3V 3.2X1.6 MOLD 5322 124 10685 S

C51 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C52 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C53 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C54 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C55 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S

C56 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C57 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C58 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C59 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C6 CAPACITOR 1 nF 20% 50V X7R 0805 5322 122 34123 S

C60 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S

C61 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S

C62 CAPACITOR 2.20 nF PME289MA4220MR04 5322 121 43756 S

C63 CAPACITOR 2.20 nF PME289MA4220MR04 5322 121 43756 S

C64 CAPACITOR 270 µF 20% SMG 400V 25X45 5322 124 80334 S

C65 CAPACITOR 100 nF 20% 250V 2222 336 20104 S

C66 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C67 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C68 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C69 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C7 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C70 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C71 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C72 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C73 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C74 CAPACITOR 68 µF 20% 6.3V SOLID AL 5322 124 10455 S

C75 CAPACITOR 33 µF 20% 63V RADIAL 2M 6.3x11 2222 037 90074 S

C76 CAPACITOR 33 µF 20% 63V RADIAL 2M 6.3x11 2222 037 90074 S

C77 CAPACITOR 10 pF 5% 50V NP0 0805 2222 861 15109 S

C78 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C79 CAPACITOR 33 µF 20% 63V RADIAL 2M 6.3x11 2222 037 90074 S

C8 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C80 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C81 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C82 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S

C83 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S

C85 CAPACITOR 22 pF 5% 50V NP0 0805 5322 122 32658 S

C86 CAPACITOR 22 pF 5% 50V NP0 0805 5322 122 32658 S

C87 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S

C88 CAPACITOR 2.20 UF 20% 6.3V 3.2X1.6 MOLD 5322 124 10685 S

C89 CAPACITOR 100 pF 5% 50V NP0 0805 2222 861 15101 S

C9 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C90 CAPACITOR 100 pF 5% 50V NP0 0805 2222 861 15101 S

C91 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S

C92 CAPACITOR 15 UF 20% 6.3V 6.0X3.2 MOLD 5322 124 11418 S

C93 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S

C94 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S

C95 CAPACITOR 100 nF 20% 25V X7R 0805 5322 126 13638 S

C96 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C97 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C98 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

C99 CAPACITOR 10 nF 20% 50V X7R 0805 5322 122 34098 S

D1 DIODE 0.10A BAT18 35V 1PF SOT23 5322 130 32076 S

D10 DIODE 1A SB140 40V DO41 5322 130 81917 S

Pos Description Part No. P

D12 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D13 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D14 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D15 DIODE BYD17G 400V 1.5A SOD87 9338 122 40701 R

D16 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D17 DIODE BYD17G 400V 1.5A SOD87 9338 122 40701 R

D18 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D19 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D2 DIODE 0.10A BAT18 35V 1PF SOT23 5322 130 32076 S

D21 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D22 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D23 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D24 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D25 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D26 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D3 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D4 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D5 DIODE 0.10A BAV99 SOT23 5322 130 34337 S

D6 DIODE 1A 1N4003/200 DO41 4822 130 31878 S

D7 DIODE 1A SB140 40V DO41 5322 130 81917 S

D8 DIODE 1A SB140 40V DO41 5322 130 81917 S

D9 BRIDGE RECTIFIER 2KBP08 2A 800V 5322 130 50474 S

F1 FUSE HOLDER 011 656 5X20mm 4822 256 30139 S

F1 FUSE 1.6A 5X20 T FST034.3119 4822 253 30024 S

J1 SOLDERING LUG 10.0X15/21 CU SN 4031 100 58390 P

J1 CONNECTOR-COAX BNC 5322 267 10004 S

J10 FLAT PIN 2.8mm E184/8 LESA SN BAND 5322 290 34064 S

J15 CONNECTOR 2 POL F095 SINGLE ROW 5322 265 44074 S

J15 CONNECTOR 2POL F095 JUMPER GREY 5322 263 50101 S

J16 CONNECTOR 2POL F095 JUMPER GREY 5322 263 50101 S

J16 CONNECTOR 3 POL F095 SINGLE ROW 5322 290 60445 S

J17 CABLE ASSY 5322 321 60669 R

J18 CONNECTOR 40 POL LOW PROFILE HEADER 5322 265 41051 S

J19 CONNECTOR 16 POL TMH-108-01-L-DW 5322 265 41013 S

J21 CONNECTOR 2POL F095 JUMPER GREY 5322 263 50101 S

J21 CONNECTOR 3 POL F095 SINGLE ROW 5322 290 60445 S

J22 CONNECTOR 2POL F095 JUMPER GREY 5322 263 50101 S

J22 CONNECTOR 3 POL F095 SINGLE ROW 5322 290 60445 S

J23 CONNECTOR 2POL F095 JUMPER GREY 5322 263 50101 S

J23 CONNECTOR 3 POL F095 SINGLE ROW 5322 290 60445 S

J24 CONNECTOR 10 POL 22-03-2101 4030-10A 5322 265 64028 S

J25 CONNECTOR 2POL F095 JUMPER GREY 5322 263 50101 S

J25 CONNECTOR 3 POL F095 SINGLE ROW 5322 290 60445 S

J29 CONNECTOR 2POL F095 JUMPER GREY 5322 263 50101 S

J29 CONNECTOR 3 POL F095 SINGLE ROW 5322 290 60445 S

J3 FLAT PIN 2.8mm E184/8 LESA SN BAND 5322 290 34064 S

J30 CONNECTOR 2POL F095 JUMPER GREY 5322 263 50101 S

J30 CONNECTOR 3 POL F095 SINGLE ROW 5322 290 60445 S

J32 CONNECTOR 20 POL LOW PROFILE HEADER 5322 265 51296 S

J4 FLAT PIN 2.8mm E184/8 LESA SN BAND 5322 290 34064 S

J5 FLAT PIN 2.8mm E184/8 LESA SN BAND 5322 290 34064 S

J6 FLAT PIN 2.8mm E184/8 LESA SN BAND 5322 290 34064 S

J7 CONNECTOR 2 POL F095 SINGLE ROW 5322 265 44074 S

J9 FLAT PIN 2.8mm E184/8 LESA SN BAND 5322 290 34064 S

K1 RELAY REED 5V PRMA-15157-3790 5322 280 20489 R

K2 RELAY REED 5V PRMA-15157-3790 5322 280 20489 R

K3 RELAY REED 5V PRMA-15157-3790 5322 280 20489 R

K4 RELAY TQ2-5 SV/1A 2pol vx 14X9X5m 5322 280 20514 R

K5 RELAY 2p vx V23042-A1003-B101 (alt.A2303) 5322 280 60557 R

L1 CHOKE 220 UH 10% NL453232T-221K 5322 157 61918 S

L10 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A

R=0.6ohm

2422 549 43133 P

L11 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A

R=0.6ohm

2422 549 43133 P

Replacement Parts, Main Board 7-7
