Pos Description Part No. P
L12 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A
R=0.6ohm
2422 549 43133 P
L13 CHOKE 4.70µH 5% LQH1N4R7J 2422 535 94048 P
L14 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A
R=0.6ohm
2422 549 43133 P
L15 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A
R=0.6ohm
2422 549 43133 P
L16 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A
R=0.6ohm
2422 549 43133 P
L17 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A
R=0.6ohm
2422 549 43133 P
L18 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A
R=0.6ohm
2422 549 43133 P
L19 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A
R=0.6ohm
2422 549 43133 P
L2 CHOKE 4S2 3.5X6MM BANDAD 80ohm at 100MHz 5322 157 61928 P
L20 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A
R=0.6ohm
2422 549 43133 P
L21 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A
R=0.6ohm
2422 549 43133 P
L22 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A
R=0.6ohm
2422 549 43133 P
L23 CHOKE 4S2 3.5X6MM BANDAD 80ohm at 100MHz 5322 157 61928 P
L24 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A
R=0.6ohm
2422 549 43133 P
L25 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A
R=0.6ohm
2422 549 43133 P
L3 CHOKE 4S2 3.5X6MM BANDAD 80ohm at 100MHz 5322 157 61928 S
L4 FILTER-EMI BLM21A102SPT Z=1Kohm 0.2A
R=0.6ohm
2422 549 43133 P
L5 CHOKE 4S2 3.5X6MM BANDAD 80ohm at 100MHz 5322 157 61928 S
L6 CHOKE 10mH B82722-J2102-N1 1A 5322 157 70143 S
L7 CHOKE 10.00µH NEWPORT 18R103 2422 536 00061 P
L8 CHOKE 10.00µH NEWPORT 18R103 2422 536 00061 P
L9 CHOKE 33µH TSL0809-330K1R2 5322 157 53568 S
Q1 TRANSISTOR BF513 .03A20V SOT23 4822 130 60686 S
Q10 TRANSISTOR 0.5A BC807-25 45V SOT23 5322 130 60845 S
Q11 TRANSISTOR 0.5A BC817-25 45V SOT23 4822 130 42804 S
Q12 TRANSISTOR BC847B .1A45V SOT23 4822 130 60511 S
Q13 TRANSISTOR BFG97 0.1A 15V SO223 4822 130 63069 S
Q14 TRANSISTOR BC847B .1A45V SOT23 4822 130 60511 S
Q15 TRANSISTOR BC857B .1A45V SOT23 5322 130 60508 S
Q16 TRANSISTOR BC847B .1A45V SOT23 4822 130 60511 S
Q17 TRANSISTOR 0.5A BC817-25 45V SOT23 4822 130 42804 S
Q2 TRANSISTOR 25 MA BFR92A 20V SOT23 5322 130 60647 S
Q24 TRANSI-NPN SMD BFG16A SOT223 1.5GHz 1W 9340 022 10701 R
Q27 TRANSI-NPN SMD BFG16A SOT223 1.5GHz 1W 9340 022 10701 R
Q28 TRANSISTOR BFT92 25MA 15V SOT23 5322 130 44711 S
Q29 TRANSISTOR BFS17 .05A 15V SOT23 5322 130 40781 S
Q3 TRANSISTOR BFS17 .05A 15V SOT23 5322 130 40781 S
Q30 TRANSISTOR BFT92 25MA 15V SOT23 5322 130 44711 S
Q31 TRANSISTOR BFS17 .05A 15V SOT23 5322 130 40781 S
Q32 TRANSISTOR BFS17 .05A 15V SOT23 5322 130 40781 S
Q33 TRANSISTOR BFS17 .05A 15V SOT23 5322 130 40781 S
Q34 TRANSISTOR BFS17 .05A 15V SOT23 5322 130 40781 S
Q35 TRANSISTOR BFS17 .05A 15V SOT23 5322 130 40781 S
Q36 TRANSISTOR BSR12 0.1A 15V SOT23 5322 130 44743 S
Q37 TRANSISTOR BSR12 0.1A 15V SOT23 5322 130 44743 S
Q38 TRANSISTOR BFS17 .05A 15V SOT23 5322 130 40781 S
Q39 TRANSISTOR BFS17 .05A 15V SOT23 5322 130 40781 S
Q4 TRANSI-HF N SMD BFR93A 35mA 12V SOT23 5322 130 60705 S
Q5 TRANSISTOR BCP51 1.5A 45V SOT223 5322 130 62639 S
Q6 TRANSISTOR BC847B .1A45V SOT23 4822 130 60511 S
Q7 TRANSISTOR 0.5A BC807-25 45V SOT23 5322 130 60845 S
R1 RESISTOR 47 ohm 1% 0.125W 100PPM 1206 5322 116 80448 S
R10 RESISTOR 120 ohm 1% 0.125W 100PPM 1206 4822 051 10121 S
R100 RESISTOR 27 ohm 1% 0.1W 100PPM 0805 4031 002 27090 S
Pos Description Part No. P
R101 RESISTOR 4.7 kohm 1% 0.125W 100PPM 1206 4822 051 54702 S
R105 RESISTOR 1.00 kohm 1% 0.125W 100PPM 1206 4822 051 51002 S
R106 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R107 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R108 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R109 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R11 RESISTOR 120 ohm 1% 0.125W 100PPM 1206 4822 051 10121 S
R110 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R111 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R112 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R113 RESISTOR 100 ohm 1% 0.1W 100PPM 0805 5322 117 12497 S
R115 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R116 RESISTOR 15.0 kohm 1% .125W 100PPM 1206 5322 116 82261 S
R117 RESISTOR 47 ohm 1% 0.1W 100PPM 0805 5322 117 12505 S
R118 RESISTOR 47 ohm 1% 0.1W 100PPM 0805 5322 117 12505 S
R119 RESISTOR 1.00 kohm 1% 0.125W 100PPM 1206 4822 051 51002 S
R12 RESISTOR 120 ohm 1% 0.125W 100PPM 1206 4822 051 10121 S
R121 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R122 RESISTOR 100 kohm 1% 0.125W 100PPM 1206 4822 051 51004 S
R123 RESISTOR 100 kohm 1% 0.125W 100PPM 1206 4822 051 51004 S
R124 RESISTOR 100 kohm 1% 0.125W 100PPM 1206 4822 051 51004 S
R125 RESISTOR 100 kohm 1% 0.125W 100PPM 1206 4822 051 51004 S
R126 RESISTOR 1.00 kohm 1% 0.125W 100PPM 1206 4822 051 51002 S
R127 RESISTOR 1.00 Mohm 1% 0.125W 100PPM 1206 4822 051 10105 S
R128 RESISTOR 1.50 kohm 1% 0.125W 100PPM 1206 4822 051 51502 S
R129 RESISTOR 470 ohm 1% .125W 100PPM 1206 4822 051 54701 S
R13 RESISTOR 120 ohm 1% 0.125W 100PPM 1206 4822 051 10121 S
R130 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R131 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R132 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R133 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R134 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R135 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R136 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R137 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R138 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R139 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R14 RESISTOR 120 ohm 1% 0.125W 100PPM 1206 4822 051 10121 S
R140 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R141 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R142 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R143 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R144 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R145 RESISTOR 330 ohm 1% .125W 100PPM 1206 4822 051 53301 S
R146 RESISTOR 15.0 kohm 1% .125W 100PPM 1206 5322 116 82261 S
R147 RESISTOR 2.20 kohm 1% .125W 100PPM 1206 4822 051 52202 S
R148 THERMISTOR 16.0 W 20% 3.5A S236/16 5322 116 30457 S
R149 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R15 RESISTOR 150 ohm 1% 0.125W 100PPM 1206 4822 051 51501 S
R150 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R151 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R152 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R153 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R154 RESISTOR 220.0 ohm 1% .125W 100PPM 1206 4822 051 52201 S
R155 RESISTOR 330 ohm 1% .125W 100PPM 1206 4822 051 53301 S
R158 RESISTOR 120 ohm 1% 0.1W 100PPM 0805 5322 117 12506 S
R159 RESISTOR 10.0 kohm 1% 0.125W 100PPM 1206 4822 051 51003 S
R16 RESISTOR 150 ohm 1% 0.125W 100PPM 1206 4822 051 51501 S
R160 RESISTOR 390 ohm 1% .125W 100PPM 1206 4822 051 53901 S
R161 RESISTOR 100 kohm 1% 0.125W 100PPM 1206 4822 051 51004 S
R162 RESISTOR 100 kohm 1% 0.125W 100PPM 1206 4822 051 51004 S
R163 RESISTOR 100 kohm 1% 0.125W 100PPM 1206 4822 051 51004 S
R164 RESISTOR 100 kohm 1% 0.125W 100PPM 1206 4822 051 51004 S
R165 RESISTOR 100 kohm 1% 0.125W 100PPM 1206 4822 051 51004 S
7-8 Replacement Parts, Main Board
