Fluke PM6685 - Replacement Parts

Replacement Parts
Pos Description Part Number P
Heat Sink 16°K/W TO220 5322 255 41313 P
Heat Sink 13.5°K/W TO220 5322 255 41314 P
C01 Capacitor 1 nF 5% 63V 4822 122 31746
C02 Capacitor 1 nF 5% 63V 4822 122 31746
C03 Capacitor 220 pF 20% 200V 5322 126 13129
C04 Capacitor 33 nF 10% 50V 4822 122 31981
C05 Capacitor 33 nF 10% 50V 4822 122 31981
C06 Capacitor 33 nF 10% 50V 4822 122 31981
C07 Capacitor 100 nF 10% 63V 4822 122 33496
C08 Capacitor 100 nF 10% 63V 4822 122 33496
C09 Capacitor 47 nF 10% 250V 4822 121 41676
C10 Capacitor 330 nF 20% 250V 5322 121 44222
C12 Capacitor 100 mF 20% 35V 5322 124 40852
C13 Capacitor 220 pF 20% 200V 5322 126 13129
C14 Capacitor 100 pF 5% 63V 4822 122 31765
C15 Capacitor 22 pF 5% 63V 4822 122 32482
C16 Capacitor 4.7nF 10% 63V 4822 122 31784
C17 Capacitor 4.7nF 10% 63V 4822 122 31784
C18 Capacitor 100 nF 10% 63V 4822 122 33496
C19 Capacitor 100 nF 10% 63V 4822 122 33496
C20 Capacitor 100 nF 10% 63V 4822 122 33496
C21 Capacitor 470 mF 20% 35V 2M 5322 126 13131
C22 Capacitor 470 mF 20% 35V 2M 5322 126 13131
C23 Capacitor 10000 mF 20% 6.3V 5322 124 80821
C24 Capacitor 1 nF 5% 63V 4822 122 31746
C25 Capacitor 100 nF 10% 63V 4822 122 33496
C26 Capacitor 100 nF 10% 63V 4822 122 33496
C27 Capacitor 100 nF 10% 63V 4822 122 33496
C28 Capacitor 220 pF 20% 200V 5322 126 13129
D01 Diode 7A BYW29/200 5322 130 32328
D02 Diode 7.5A MBR760 60V 5322 130 83602
D03 Diode 7A BYW29/200 5322 130 32328
D04 Diode 0.2A BAV23 200V 5322 130 33764
D06 Diode 0.35 W BZX84-C8V2 5322 130 80255
D07 Diode BYV26E DOD57 4822 130 60815
D08 Diode 0.35 W BZX84-C18 5322 130 80212
D09 Diode 0.2A BAV23 200V 5322 130 33764
D11 Diode 0.35 W BZX84-C18 5322 130 80212
D12 Diode 0.35 W BZX84-C18 5322 130 80212
D13 Diode 0.35 W BZX84-C8V2 5322 130 80255
D14 Diode 0.2A BAV23 200V 5322 130 33764
R01 Resistor 82 kW 1% .125W 4822 051 10829
R02 Resistor 82 kW 1% .125W 4822 051 10829
R03 Resistor 270 kW 1% .125W 4822 051 10271
R04 Resistor 10.0 kW 1% 0.125W 4822 051 51003
R06 Resistor 2.20 kW 1% .125W 5322 116 80434
R07 Resistor 1.00 kW 1% 0.125W 4822 051 51002
R08 Resistor 1.80 kW 1% .125W 4822 051 10182
R09 Resistor 3.90 kW 1% .125W 5322 116 80443
R10 Resistor 47 kW 1% .125W 5322 116 80446
R11 Resistor 220 kW 1% .125W 5322 116 80436
R12 Resistor 10.0 kW 1% 0.125W 4822 051 51003
R13 Resistor 10.0 kW 1% 0.125W 4822 051 51003
R14 Resistor 10.0 W 1% 0.125W 4822 051 51003
R15 Resistor 10.0 kW 1% 0.125W 4822 051 51003
R16 Resistor 10.0 kW 1% 0.125W 4822 051 51003
Pos Description Part Number P
R17 Resistor 10.0 kW 1% 0.125W 4822 051 51003
R18 Resistor 10.0 kW 1% 0.125W 4822 051 51003
R19 Resistor 10.0 kW 1% 0.125W 4822 051 51003
R20 Resistor 10.0 kW 1% 0.125W 4822 051 51003
R24 Resistor 100 kW 1% 0.125W 4822 051 51004
R25 Resistor 100 kW 1% 0.125W 4822 051 51004
R26 Resistor 100 kW 1% 0.125W 4822 051 51004
R27 Resistor 100 kW 1% 0.125W 4822 051 51004
R28 Resistor 10.0 kW 1% 0.125W 4822 051 51003
R29 Resistor 4.7 W 10% 0.25W 4833 051 10478
R30 Resistor 10.0 kW 1% 0.125W 4822 051 51003
R31 Resistor 100 kW 1% 0.125W 4822 051 51004
R32 Resistor 100 kW 1% 0.125W 4822 051 51004
R33 Resistor 10.0 W 1% 0.125W 4822 051 10109
R34 Resistor 1.00 kW 1% 0.125W 4822 051 51002
R35 Resistor 2.7 W 5% 0.25W 4822 051 10278
R36 Resistor 2.7 W 5% 0.25W 4822 051 10278
R37 Resistor 2.7 W 5% 0.25W 4822 051 10278
R38 Resistor 1.00 kW 1% 0.125W 4822 051 51002
R39 Resistor 10.0 W 1% 0.125W 4822 051 10109
R40 Resistor 100 W 1% 0.125W 5322 116 80426
R41 Resistor 100 W 1% 0.125W 5322 116 80426
R42 Resistor 1.00 kW 1% 0.125W 4822 051 51002
R43 Resistor 100 W 1% 0.125W 5322 116 80426
R44 Resistor 100 W 1% 0.125W 5322 116 80426
R45 Resistor 1.00 kW 1% 0.125W 4822 051 51002
R46 Varistor 95V 95VRMS4.1J 5322 116 21222 P
R47 Resistor 4.70 kW 1% .125W 5322 116 80445
R48 Resistor 10.0 kW 1% 0.125W 4822 051 51003
R49 Resistor 22.0 kW 1% .125W 5322 116 80435
R50 Potentiometer 1 kW 20% 4822 101 10792
R51 Resistor 3.30 kW 1% .125W 4822 051 53302
R52 Resistor 8.20 kW 1% .125W 4822 051 10822
R53 Resistor 470 kW 1% .125W 5322 116 80447
R54 Resistor 470 kW 1% .125W 5322 116 80447
R55 Resistor 2.7 W 5% 0.25W 4822 051 10278
R56 Resistor 100 W 1% 0.125W 5322 116 80426
R57
Resistor 47 W 1% .125W
5322 116 80448
R58 Resistor 270 W 1% .125W 4822 051 10271
T01 Transformer 5322 148 20035 P
U01 IC-ref 2.5V TL431I-D SO8 5322 209 62422
U02 Optocoupler CNX82A 4822 130 10025
V02 Transistor 0.50 A BC807-25 5322 130 60845
V03 Transistor 0.50 A BC817-25 4822 130 42804
V04 Transistor 0.50 A BC817-25 4822 130 42804
V05 Transistor 0.50 A BC817-25 4822 130 42804
V06 Transistor 0.50 A BC817-25 4822 130 42804
V07 Transistor 0.50 A BC817-25 4822 130 42804
V08 Transistor 0.50 A BC807-25 5322 130 60845
9-8 Replacement Parts
