Fluke PM6690 Operator's Manual

Arming Input:
Freq. Range:
Slew Rate:
Trigger Level:
Trigger Slope:
Arming of all meas. func.
DC - 80 MHz
>2 V/ms
TTL, 1.4 V nom.
Positive or negative
Meas. Inputs:
Impedance:
A, B, C (option)
1MW//50 pF or 50 W
(VSWR £ 2:1)
Connectors: BNC (SMA for Input C)
Auxiliary Functions
Trigger Hold-Off
Time Delay
Range: 20 ns - 2 s, 10 ns resol.
External Start/Stop Arming
Modes: Start arming, stop arming,
start and stop arming
Input Channels: A, B, E
Max. Rep. Rate
for Arming Signal
Channel A, B:
Channel E:
160 MHz
80 MHz
Start Time Delay
Range: 10 ns - 2 s, 10 ns resol.
NOTE: Stop arming has no delay setting.
Statistics
Functions: Maximum, minimum,
mean, D
max-min
, standard
deviation, Allan deviation
Display:
Graphic:
Numeric or numeric +
graphic
Histogram & trend plot,
auto scaled
Sample Size: 2to2x10
9
Max. Sample
Rate: 250 kSa/s measured,
2 kSa/s calculated,
depending on meas. func
-
tion and graphics
Limit Qualifier: Off
Capture & store values
above limit 2
Capture & store values
below limit 1
Capture & store values in
-
side limits 1 and 2
Capture & store values
outside limits 1 and 2
Meas. Pacing
Time Range:
Max. Pacing
Rate:
Equidistancy:
2 ms - 500 s
10 k measurements/s
±(10 ms + 5% of pacing
time)
Mathematics
Functions: K
*
X+L, K/X+L, (K
*
X/M+L),
and (K/X+L)/M
X is current reading. K, L
and M are constants, set
via keyboard or as frozen
reference value (X
0
).
Other Functions
Measuring Time: 20 ns - 1000 s for Period
AVG, Frequency and
PRF, 20 ns - 2 s for Freq.
in Burst; Single cycle for
other meas. functions.
Times >2 s are software
controlled w. reduced res
-
olution and accuracy.
Timebase
Reference: Internal, external or auto
-
matic
Auxiliary Functions 8-7
Specifications

Fluke PM6690 Specifications
