Fluke PM6690 Operator's Manual

Performance Check
7-4 Front Panel Controls
Key(s) Display Notes P/F
STANDBY Off
Red standby LED On (Key common to ON)
ON Backlight On
Red standby LED Off (Key common to
STANDBY)
INPUT A Input A:
Menu for setting Slope, Coupling, Impedance
etc.
Man
Trig Trig: xy mV
Menu for entering numeric values in V or mV
0.123V Trig: 0.123 V
t (5 times) Trig: _ V
4.567 Trig: 4.567 V
t (5 times) Trig: _ V
8.9 Trig: 8.9 V
± Trig: -8.9 V
mV Trig: -8.9 mV
V Trig: -8.9 V
AUTOSET Menu disappears
INPUT B Input B:
Menu for setting Slope, Coupling, Impedance
etc.
SETTINGS Settings:
Menu for setting Meas Time, Hold-Off, Ref.
Source etc.
ENTER Meas Time: 200 ms
p Meas Time: 500 ms
q Meas Time: 200 ms
EXIT/OK Settings:
Menu for setting Meas Time, Hold-Off, Ref.
Source etc.
EXIT/OK Menu disappears
MATH/LIM Math/Limit:
Menu for selecting post-processing formula and
alarm limit
USER OPT User options:
Menu for Calibration, Memory Management, In
-
terface etc.
CANCEL Menu disappears
HOLD/RUN Hold
At upper right corner
HOLD/RUN Hold disappears
MEAS FUNC Measure function:
Menu for selecting measurement function
