● Dimensions: 135 x 79 x 20 mm
● Weight: 185 g
● Supply voltage: 10 ~ 30 V=
● Supply current: 50mA Max
● Operational temperature range: -20 ~ +70°C
● 1 CAN Bus communication interface
● 4 programmable outputs (active low, 300mA / 4W max)
SENSORS INPUTS:
● Current input from Flybox® sensor
● 2 Fuel flow inputs from Flybox® transducer
● Fuel pressure from Flybox® transducer
● RPM tachometer input
● Rotor tachometer input for helicopter version
● Oil pressure from Flybox®, ROTAX or JABIRU sensors
● 2 Oil temperature inputs from ROTAX, JABIRU or
PT1000 sensors
● Carburetor/Airbox from PT1000 sensor
● Outside air temperature from PT1000 sensor
● 6 Cylinder head temperature from ROTAX, J-type
thermocouples or PT1000 sensors
● 6 Exhaust gas temperature from K-type thermocouples
● 3 inputs for fuel level sensors: resistive (300 ohm max)
or capacitive (0-5V)
