FMS Fox - Programmable Functions Overview

55
c) Programmable Functions
The following programming table shows which function is assigned to which sound sequence or melody. Punctuati-
on marks (e.g. star or dash) designate individual sounds.
Letters mean that a small melody sounds.
Function Selection Sound sequence / melody
1 Brake off / on
_* _* _* _*
2 Battery type NiMH
~ ~ ~ ~
2.1 Battery type LiPo
~ ~ ~ ~ ~ ~ ~ ~
3 Undervoltage recognition (50%) 2.8 V/cell
*_ _* *_ _* *_ _* *_ _*
3.1 Undervoltage recognition (60%) 3.0 V/cell
*_ _ _* *_ _ _* *_ _ _* *_ _ _*
3.2 Undervoltage recognition (65%) 3.2 V/cell
*_ _ _ _* *_ _ _ _* *_ _ _ _* *_ _ _ _*
4 Works settings
__ __ __ __
5 Motor Timing Automatic (7-30°)
_ _ _ _
5.1 Motor Timing low (7-22°)
_ _ _ _ _ _ _ _
5.2 Motor Timing high (22-30°)
_ _ _ _ _ _ _ _ _ _ _ _
6 Start-Up Characteristics very soft
V V V V V V V V
6.1 Start-Up Characteristics soft
V V V V
6.2 Start-Up Characteristics normal
V V V V V V V V V V V V
7 Govenor-Mode off
_*_ _*_ _*_ _*_
7.1 Govenor-Mode Heli Mode 1
_**_ _**_ _**_ _**_
7.2 Govenor-Mode Heli Mode 2
_***_ _***_ _***_ _***_
8 Motor Rotating Direction left / right
W W W W
9 Cycle Frequency of the Flight Controller 8 kHz
// // // //
9.1 Cycle Frequency of the Flight Controller 16 kHz
\\ \\ \\ \\
10 Behaviour in Case of Undervoltage Reduce power
__– __– __– __–
10.1 Behaviour in Case of Undervoltage Deactivate motor
– __– __– __–
