15. Replacing the Folding Propeller
The individual propeller blades are fastened with an M3 screw (1) and a matching stop nut (2) at the middle part of
the propeller. If you want to replace the entire folding propeller with spinner, carefully compress the spinner (3) as
shown in gure 12 and lift it off. Then remove the nut (4) of the propeller tappet.
Figure 12
