FMS Fox - Technical Specifications; Flight Model Specifications; Motor and Propeller Specifications; Flight Controller Specifications

61
18. Technical Data
a) Flight Model
Wing Span ............................................2320 mm
Length...................................................1290 mm
Wing area .............................................37.8 dm²
Area load ..............................................47.1 g/dm²
Weight incl. rechargeable battery .........1150 g
b) Motor and Propeller
Type ......................................................Brushless, 900 KV
Suitable for ...........................................3 LiPo cells
Propeller ...............................................30.48 x 15.24 cm (12“ x 6“)
c) Flight Controller
Voltage range .......................................2 - 4 cells LiPo
Important!
The ight controller can be operated with 2 - 4 cells LiPo, but the ight model and the motor used is
designed for 3 cells LiPo only.
Current capacity ...................................Permanent current 35 A (for 10 seconds: 45 A)
BEC ......................................................linear, 5 V/DC, 4 A
Plug system ..........................................T-Connector
d) Required Remote Control System (Not Enclosed)
Transmission frequency........................2.4 GHz (recommended)
Number of channels .............................at least 5 (programmable computer remote control recommended from 6
channels onwards)
e) Required Flight Battery (Not Enclosed)
Battery type ..........................................3-cell LiPo battery, rated voltage 11.1 V, capacity min. 1200 mAh, discharge
rate min. 25C
