Quickstart
FS-100 Portable DTE Recorder 13
Bottom Panel
The FS-100 bottom panel features a single 2-pin DC power
connector. Connect the supplied AC power adapter here.
Internal Speaker
An internal speaker provides alarms and audible feedback.
To disable the audible feedback, go to the Settings menu and
select
ALARM OFF. However, the power, temperature, and disk
capacity alarms are always active.
Cooling Vent
Do Not Block
DC
Power
Connector
Internal
Speaker
