FS-100 Functions
40 FS-100 Portable DTE Recorder
10. Reel Display
In
Record or Playback modes, this item displays the particular
REEL that a clip is located in or, has been marked to. If in
PLAY FROM > REEL LIST mode, the REEL appears in
brackets for example, [REEL]. This area is blank if
NO REEL
has been selected.
11.
DISP information field that displays data type.
12.
DISP information field that displays current data.
DISP (display) Information Fields
Use the DISP function button to display current operation
information fields 11 and 12. The data shown depends on the
mode of operation, i.e.
DVCPROHD, DVCPRO50, DVCPRO/DV.
Pressing the
DISP button advances the display to the next
category of information. Below is a table of the data types and
data available with
DISP.
Field
Number
Data Type /
Data Description
11 COUNTER
12 Shows frame count of current video clip during record or
playback.
11 REMAINING
12
Record: counts down number of available frames remaining,
as time, on a specific disk.
Playback: displays time remaining of the current clip.
11 DV (NTSC or PAL) or HD (see note following table)
12
Record: displays the external timecode value being generated
by a camcorder or other device during a recording session.
Timecode mode must be set to
EXT TC for this function to
operate, refer to TIME CODE EXT, REC RUN, FREE RUN,
REGEN on page 57.
Playback: displays the embedded DV timecode value in a
particular track.
11 UB NTSC
12 Displays the set user bit value in a particular clip. A user bit
value must be added for this to display, refer to UB SET on
page 59.
11 ABSOLUTE
12 Displays an absolute timecode value for the particular session:
the sum of all COUNTER timecodes on connected volumes.
Absolute is primarily used when setting the FS-100 to AV/C
mode and controlling it with an external FireWire device, such
as a computer.
