68
14 : SETUP MENUS
PARAMETER
Description
SCENE SELECT, SCENE INCR,
SCENE DECR
These options allow selecting SCENES via MIDI CC#.
For SCENE SELECT, the value of the Control Change message determines
which scene is loaded. The easy rule is Scene number -1 = CC# Data Value.
(Ex: Scene 1, Value 0).
However, values greater than 7 continue to select scenes, in order. To
determine the scene for values >7, add 1 and divide by 8. The REMAINDER
is the scene that will be selected. Ex: 62+1 = 63, 63 ÷ 8 = 7 remainder 7, so
63 loads scene 7.
SCENE INCR and DECR are triggered by CC# data values greater than 63.
OUT POST VOL INCR,
OUT POST VOL DECR
NONE/PEDAL…/0-127
These two options provide a convenient way to increase or decrease the
OUT 2 (POST) VOLUME volume of the currently loaded scene in the current
preset. Each time VOL INCR is triggered by a CC# value greater than 63, the
level is increased by 1.0 dB and the preset is instantly saved. VOLUME DECR,
works the same way, decreasing volume.
IMPORTANT! Any other unsaved changes such as altered eects will also be
stored if either VOLUME INCR or VOLUME DECR is triggered. WARNING!
These functions are designed for use with momentary footswitches set
up to send a CC# value of 127 for “ON” and 0 for “OFF”. Do not use an
expression pedal or you may change levels +/-20 dB with a single sweep!
CHORUS 1 BYP
through
VOLUME/PAN BYP
The BYPASS switch for every block in the FX8 can be remote controlled. The
list of MIDI CC# defaults can be found on page 80. Some blocks may not
have a default assignment but you can change any block at any time.
CHORUS 1 XY
through
WAHWAH 2 XY
Like the BYPASS switch (above) the XY toggle switch for every block can be
remote controlled. The list of defaults is on page 80.
I/O: PEDAL PAGES
The functions of the PEDAL page are detailed in “Connecting Pedals & Switches” on page 16.
