16 : SPECIFICATIONS & DEFAULTS
INPUT PRE:
Connector: 1/4” phone jack, unbalanced.
Impedance: 1 Megohm (less if Input Impedance is active)
Max. Input Level: +16 dBu (conditioned for guitar use)
INPUT POST:
Connector: 1/4” phone jack, balanced.
Impedance: 1 Megohm
Max. Input Level: +20 dBu
A/D CONVERSION
Bit Depth: 24 bits
Sample Rate: 48 kHz
Dynamic Range: > 110 dB
Frequency Response: 20 – 20kHz, +0 / -1 dB
Crosstalk: < -60 dB over full bandwidth
ANALOG OUTPUTS
Connectors: 1/4” phone jack unbalanced (Humbuster™ hum-canceling type)
Impedance: 600 ohm
Max Output Level: +20 dBu
Dynamic Range: > 110 dB
Frequency Response: 20 – 20kHz, +0 / -1 dB
Crosstalk: < -60 dB over full bandwidth
MIDI INTERFACE
Connectors (in and out/thru): 5-pin DIN
PEDAL INTERFACE
Connector: 2 x 1/4” TRS phone jacks
Format: Switch: Momentary or Latching; Pedal: 10–100kΩ max, linear taper expression type.
RELAY INTERFACE
Connector: 2 x 1/4” TRS phone jacks
Type: Short tip-to-sleeve, ring-to-sleeve, tip-AND-ring-to-sleeve
USB INTERFACE:
Connector: USB 2.0 Type B
GENERAL
Finish: Powder coated steel chassis with anodized aluminum faceplate
Display: 160x80 dot matrix graphic LCD
Dimensions: 16.35” x 3.96” x 10.00” (415.29mm x 100.6mm x 254mm)
Weight: 11.5 lbs. (5.2 kg)
Input Voltage: 100–240 VAC, 47 – 63 Hz (universal input)
Power Consumption: <40 W
ENVIRONMENTAL
Operating Temperature: 32 to 122 °F (0 to 50 °C)
Storage Temperature: -22 to 167 °F (-30 to 70 °C)
Humidity: Max. 90% non-condensing
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
