5.5.10.5 Drive motors
In this display the LCD will display the following information:
1.Left drive current (A2D) 2.Right drive current (A2D) 3.Right drive temperature (ºC)
4.Over current counter 5.Hardware over current 6.Right drive temperature (A2D)
1.Left drive current (A2D) 2.Right drive current (A2D) 3.Right drive temperature (ºC)
4.Over current counter 5.Hardware over current 6.Right drive temperature (A2D)
1.Left drive current (A2D) 2.Right drive current (A2D) 3.Right drive temperature (ºC)
4.Over current counter 5.Hardware over current 6.Right drive temperature (A2D)
1. Left drive current.
Left drive current in a2d.
2. Right drive current.
Right drive current in a2d.
3. Right drive temperature (ºC).
Right drive temperature in ºC.
4. Over current counter.
Indicates if drive over current is detected either by Hardware current limiter or by
Software current readings.
0 – No over current
Otherwise - over current.
5. Hardware over current.
Indicates if drive over current is detected by Hardware current limiter.
0 – Over current not detected.
1 - Over current detected
6. Right drive temperature (a2d).
Right drive temperature in a2d.
5.5.10.6 Mow motors
In this display the LCD will display the following information:
1.Left mow current (A2D) 2.Middle mow current (A2D) 3.Right mow current (A2D)
4.Over current counter 5.Hardware over current 6.Temperature (ºC). or over current event counter
1.Left mow current (A2D) 2.Middle mow current (A2D) 3.Right mow current (A2D)
4.Over current counter 5.Hardware over current 6.Temperature (ºC). or over current event counter
1.Left mow current (A2D) 2.Middle mow current (A2D) 3.Right mow current (A2D)
4.Over current counter 5.Hardware over current 6.Temperature (ºC). or over current event counter
1. Left mow current.
Left mow current in a2d.
2. Middle mow current.
Middle mow current in a2d.
3. Right mow current.
Right mow current in a2d.
4. Over current counter.
Indicates if mow over current is detected either by Hardware current limiter or by
Software current readings.
0 – No over current
Otherwise - over current
