Friendly Robotics robomower RL800 - Parts List

1.6 Spare Parts List
1.6.1 Spare Parts – sorted by item number
24
#
Friendly P/N
(2006)
Friendly P/N
(2005)
Part Description
Appears in
Exploded views
No.
No. of
parts
1 GEN0094A GEN0094A RL Yellow cover
1.1.1 1
1 GEN0227A GEN0227A RL Green cover
1.1.1 1
2 MSB0112A MSB0112A Manual controller- Europe (tones)
1.1.1 & 1.2.3 1
2 MSB0114A MSB0114A Manual Controller - US
1.1.1 & 1.2.3 1
2 MSB0118A MSB0117A Manual controller (ESBC050B and forwards)
1.1.1 & 1.2.3 1
2 MSB0119A -------- Enhanced Manual Controller
1.1.1 & 1.2.3 1
3 MSB0078A MSB0078A Smooth drive wheel + bearing
1.1.1 & 1.2.1 2
3 MSB0099A MSB0099A Knobby drive wheel + bearing
1.1.2 2
4 UNT0009A UNT0009A Power Pack
1.1.1 & 1.2.6 1
5 MSB0107A MSB0107A Rear bumper assembl
y
1.2.8 1
6 SPP0032A SPP0032A operation lamp cover + seal 1.1.1 & 1.2.3 1
7 MSB0105B MSB0105B Man. cont. holder assembl
y
(
sp
)
1.1.1 & 1.2.3 1
8 STC0048A STC0048A RL550 Sticker
1.1.1 1
8 STC0049A STC0049A RL850 Sticker
1.1.1 1
8 STC0051A STC0051A RL800 Sticker
1.1.1 1
8 STC0056A STC0056A RL1000 Sticker
1.1.1 1
8 STC0057A STC0057A RL350 Sticker
1.1.1 1
9 SPP0026A SPP0026A Charging contact (for Docking Station) + screws
1.1.1 & 1.2.3 1
10 MSB0106B MSB0106B Front bumper (one spring) assembly
1.2.8 1
11 SPP0011A SPP0011A Front wheel with axle
1.1.2 & 1.2.10 1
12 MSB0065B MSB0065B Mowing Unit + cable
1.2.1 & 1.1.3 3
13 GEN0095A GEN0095A RL plastic base
1.1.2 1
14 GEN0162A GEN0162A Snap lock (straight)
1.1.2 6
15 SPP0012A SPP0012A Sin
g
le hi
g
h cut blade
1.1.2 & 1.2.11 3
15 SPP0013A SPP0013A Sin
g
le low cut blade
1.1.2 & 1.2.11 3
16 GEN0163A GEN0163A Snap lock (curved)
1.1.2 4
17 SPP0018A SPP0018A Wire Sensors x4 with cable (+DOC0057A)
1.1.3 1
18 GEN0182A GEN0182A Cover-base seal ring
1.2.2 1
19 ESBC024C ESBC024B Odometer Board R
1.1.3 & 1.4.3 1
20 SPP0014A SPP0014A Batter
y
contacts assembl
y
(
RL side
)
1.1.3 & 1.2.2 2
21 SPP0020A SPP0020A Thermistors kit
1.1.3 & 1.2.11 1
22 GEN0202A GEN0202A Ground clearance limiter
1.1.3 & 1.2.5 1
23 SPP0008B SPP0008B Drive motor replacement kit
1.1.3 & 1.2.5 2
24 ESBC025C ESBC025B Odometer Board L
1.1.3 & 1.4.3 1
25 SPP0019B SPP0019B Main Board (ESBC050B)
1.1.3 & 1.4.1 1
26 GEN0210A GEN0210A Charging socket rubber cover
1.2.12 1
27 GEN0208A GEN0208A Front Wheel stopper spring
1.2.2 & 1.1.3 2
28 GEN0207A GEN0207A Front Wheel stopper
1.2.2 & 1.1.3 1
29 SPP0030A SPP0030A
Charging Station Cover (includes lexan, screws, sticker
and push button
)
1.2.4 1
30 SPP0029A SPP0029A Charging Station Base (Yellow)
1.2.4 1
30 SPP0039A SPP0039A Char
g
in
g
Station Base
(
Green
)
1.2.4 1
31 GEN0215C GEN0215B Dockin
g
Station Fence
(
Green
)
1.2.4 1
32 SPP0031A SPP0031A Dockin
g
Station Contacts Assembl
y
1.2.4 1
33 STC0054A STC0054A Char
g
in
g
station cover sticker
1.1.4 1
34 GEN0140A GEN0140A Sealing cup
1.2.1 4
35 ESB0022B ESB0022B Lamp Board
1.2.1 1
36 GEN0133A GEN0133A Magnet for Manual Controller
1.2.1 1
37 RNG0005A RNG0005A Spacer for Drive Wheel - D18*D12*0.5 DIN 988
1.2.1 2 to 8
38 RNG0002A RNG0002A Retaining ring for 12mm shaft (for Drive Wheel)
1.2.1 2
