1.6.1 Spare Parts – sorted by item number (con.)
#
Friendly P/N
(2006)
Friendly P/N
(2005)
Part Description
Appears in
Exploded views
No.
No. of
parts
39 GEN0104A GEN0104A Wheel Cup (gray)
1.2.1 2
39 GEN0201A GEN0201A Wheel Cup (black)
1.1.3 & 1.2.1 2
40 GEN0146A GEN0146A Main board rubber holder
1.2.2 4
41 CPS0007A CPS0007A Wire twist lock
1.2.2
42 GEN0171A GEN0171A Motor shading
1.2.2 5
43 ESBC021C ESBC021C Connectors Board
1.2.2 & 1.4.2 1
44 SPP0004C SPP0004B Spare part gear case
1.2.2 & 1.2.5 1
45 GEN0142A GEN0142A Connector's cover
1.2.3 1
46 GEN0145A GEN0145A Pivot for manual controller's tray
1.2.3 2
47 LMP0004A LMP0004A Operating bulb bayonet 24v/4w
1.2.3 1
48 SCR0029A SCR0029A Screw DIN 7981C A2 4.2x25
(
Dockin
g
Station
)
1.2.4 5
49 SPP0028B SPP0028A
Charging Station Board (includes screws, tact switch
cover and push button
)
1.2.4 1
50 SCR0027A SCR0027A Screw WN 1412 KA25x8
(
Dockin
g
Board
)
1.2.4 8
51 GEN0176A GEN0176A Dockin
g
Board seal
1.2.4 1
52 GEN0218A GEN0218A Push button for Dockin
g
Board
1.2.4 1
53 GEN0223A GEN0223A Fastening Stakes for the Charging Station
1.2.4 5
54 GEN0217B GEN0217B D. Station Connectors Cover
(
Green
)
1.2.4 3
55 SPP0009B SPP0009A Gear Shafts replacement kit
1.2.5 1
56 SPP0015A SPP0015A Gear Frame (+ GEN0202A and DOC0056A)
1.2.5 1
57 GEN0122A GEN0122A Shafts clamp
(
g
ear
)
1.2.5 2
58 MSB0077A MSB0077A Slider assembly
1.2.5 2
59 MSB0079A MSB0079A Gear spline + bearing
1.2.5 2
60 GEN0101A GEN0101A Odometer ma
g
net
1.2.5 4
61 SCR0025A SCR0025A Screw for RL motors
1.2.5 8
62 GEN0132A GEN0132A Battery cover
1.2.6 1
63 GEN0131A GEN0131A Batter
y
Case
1.2.6 1
64 GEN0130A GEN0130A Contact leaf-battery
1.2.6 2
65 PWS0004A PWS0004A 230VAC Out Door Power Supply (EUR)
1.2.6 1
65 PWS0005A PWS0005A 115VAC Out Door Power Suppl
y
(
US
)
1.2.6 1
65 PWS0006A PWS0006A 230VAC Out Door Power Suppl
y
(
UK
)
1.2.6 1
66 PWS0001A PWS0001A 230VAC power supply -Europe
1.2.6 1
66 PWS0002A PWS0002A 230VAC power supply - UK
1.2.6 1
66 PWS0003A PWS0003A 115VAC power supply - US
1.2.6 1
67 CBL0037A CBL0037A External charger cord - UK
1.2.6 1
67 CBL0038A CBL0038A External char
g
er cord - US
1.2.6 1
67 CBL0039A CBL0039A External char
g
er cord - EUR
1.2.6 1
68 UNT0016A UNT0016A Power Pack external charging adaptor
1.2.6 1
69 FUS0021A FUS0021A Fuse 5x20 10A 125V
(
External Char
g
er
)
1.2.7 & 1.3 1
70 FUS0015A FUS0015A Fuse mini blade 5A
1.2.7 & 1.3 1
71 FUS0003A FUS0003A Fuse AT blade 30A 32V
1.2.7 & 1.3 1
72 FUS0012A FUS0012A Fuse AT blade 1A 32V
1.2.7 & 1.3 1
73 MRK0025B MRK0025B 5 hrs. Perimeter Switch
1.2.8 1
74 GEN0156A GEN0156A Perimeter switch back cover
1.2.8 1
75 GEN0175A GEN0175A Stake for perimeter switch
1.2.8 1
76
BAT0003A BAT0003A Battery holder for perim.switch with screws 1.2.8 1
77 CON0054A CON0054A Plot connector
1.2.8 1
78 MSB0090A MSB0090A Contact strip front assembly
1.2.8 1
79 MSB0091B MSB0091B Contact strip rear assembly
1.2.8 1
80 RNG0031A RNG0030A Washer M10x15
(
BN 739
)
1.2.10 1
81 GEN0117A GEN0117A Adjusting bolt
1.2.10 1
82 SPP0005B SPP0005B Drop off board + holder 1.2.10 1
