1.6.1 Spare Parts – sorted by item number (con.)
#
Friendly P/N
(2006)
Friendly P/N
(2005)
Part Description
Appears in
Exploded views
No.
No. of
parts
83 GEN0116A GEN0116A Drop off flag
1.2.10 1
84 NIT0009A NIT0009A Pop rivet/D3.2x6 (Thermistors)
1.2.11 2
85 HSN0003A HSN0003A Heat sink silicone insulator (Thermistors)
1.2.11 2
86 DOC0015D DOC0015C RL Operating Manual (En)
1.2.12 1
86 DOC0076B DOC0076A RL1000 + Docking Manual (En)
1.2.12 1
87 GEN0211A GEN0211A charging plug rubber cover
1.2.12 1
88 TOL0001A TOL0001A Mowing motor removal tool
1.1.12 1
89 STC0018A STC0018A Danger sticker
1.2.13 2
90 STC0022A STC0022A Front caution sticker
1.2.13 1
91 STC0012A STC0012A Rear warning sticker
1.2.13 1
92 STC0036B STC0036B Battery charging decal (En)
1.2.13 1
93 STC0055A STC0055A Charging Station fence sticker
1.2.13 1
94 SPP0027A SPP0027A Flash Software v3.2a+ (ESB0019C)
1.2.14 1
95 ESB0031A ESB0031A Rear Right Wire Sensor Board (old configuration)
1.2.14 1
96 WSB0025B WSB0025B Perim. wire to perim. switch cable
1.2.14 1
97 GEN0148A GEN0148A Navigator keypad
1.2.14 1
98 WSB0053A WSB0053A Mowing motors cable
1.2.14 & 1.4.1 3
99 GEN0118A GEN0118A Front Wheel Click Spring ('02 configuration)
1.2.14 1
100 WSB0035A WSB0035A Main board to battery cable
1.4.1 & 1.5.1 1
101 WSB0052A WSB0052A Flat cable
1.4.1 & 1.5.1 1
102 WSB0041A WSB0041A Odometers cable
1.4.1 & 1.5.1 1
103 WSB0043B WSB0043B Bumper cable
1.4.1 & 1.5.1 1
104 WSB0063A WSB0063A Drive motor + ferrite cable
1.4.1 & 1.5.1 1
105 WSB0044A WSB0044A Lamp board cable
1.2.3 & 1.5.1 1
106 WSB0046B WSB0046A Fuse holder battery pack cable
1.5.2 1
107 WSB0048B WSB0048A (-) spring battery cable
1.5.2 1
108 WSB0049B WSB0049A Battery jumper cable
1.5.2 1
109 WSB0070A WSB0070A Connector Board to char
g
in
g
contacts cable
1.5.1 1
110 DOC0008B DOC0008B RoboRuler
NA 1
111 DOC0051E DOC0051D RL Service Guide Hard Copy (En)
NA
112 DOC0053C DOC0053B RL Service Guide CD (En)
NA
113 DOC0065B --------- RL Operating & Safety CD (En)
NA
114 PRG0005A PRG0005A Flash Software v3.2i (Service version - 03 models)
NA
115 SPP0033C SPP0033B Flash Software v3.2-06 + Operating Manual (En)
NA
115 SPP0035C SPP0035B Flash Software v3.2-06 + Operating Manual (BLX)
NA
115 SPP0036C SPP0036B Flash Software v3.2-06 + Operating Manual (DE)
NA
115 SPP0040C -------- Flash Software v3.2-06 + Operating Manual (IT)
NA
115 SPP0041C -------- Flash Software v3.2-06 + Operating Manual (DK)
NA
115 SPP0101A -------- Flash Software v4.1-06 + Operatin
g
Manual
(
En
)
NA
115 SPP0102A -------- Flash Software v4.1-06 + Operatin
g
Manual
(
BLX
)
NA
115 SPP0103A -------- Flash Software v4.1-06 + Operatin
g
Manual
(
DE
)
NA
115 SPP0104A -------- Flash Software v4.1-06 + Operatin
g
Manual
(
IT
)
NA
115 SPP0105A -------- Flash Software v4.1-06 + Operating Manual (DK)
NA
116 CPS0013A CPS0013A Wire twist lock for bat. cable
NA
1
120 STC0052A STC0052A Theft Guard decal
NA
121 GEN0067A GEN0067A Fast charger 115/230V (without cord)
1.2.6
122
GEN0229A
--------
Charging Station right wheel support 1.1.4 & 1.2.4 1
123
GEN0230A
--------
Charging Station left wheel support 1.1.4 & 1.2.4 1
124 STC0058A ------- Crossed-out wheeled bin
1
125
GEN0231A
--------
Gear frame support
126
CPS0014A
--------
Plastic rivet (between cover and base)
127 SCR0033A -------- Screw for the Charging Station drive wheel supports
1.2.4 2
1
26
