1.6.2 Spare Parts – sorted by Friendly part number
27
#
Friendly P/N
(2006)
Friendly P/N
(2005)
Part Description
Appears in
Exploded views
No.
No. of
parts
76
BAT0003A BAT0003A Battery holder for perim.switch with screws 1.2.8 1
67 CBL0037A CBL0037A External char
g
er cord - UK
1.2.6 1
67 CBL0038A CBL0038A External char
g
er cord - US
1.2.6 1
67 CBL0039A CBL0039A External char
g
er cord - EUR
1.2.6 1
77 CON0054A CON0054A Plot connector
1.2.8 1
41 CPS0007A CPS0007A Wire twist lock
1.2.2
116 CPS0013A CPS0013A Wire twist lock for bat. cable
NA
1
126
CPS0014A
--------
Plastic rivet (between cover and base)
110 DOC0008B DOC0008B RoboRuler
NA 1
86 DOC0015D DOC0015C RL Operating Manual (En)
1.2.12 1
111 DOC0051E DOC0051D RL Service Guide Hard Copy (En)
NA
112 DOC0053C DOC0053B RL Service Guide CD (En)
NA
113 DOC0065B --------- RL Operating & Safety CD (En)
NA
86 DOC0076B DOC0076A RL1000 + Docking Manual (En)
1.2.12 1
35 ESB0022B ESB0022B Lamp Board
1.2.1 1
95 ESB0031A ESB0031A Rear Right Wire Sensor Board (old configuration)
1.2.14 1
43 ESBC021C ESBC021C Connectors Board
1.2.2 & 1.4.2 1
19 ESBC024C ESBC024B Odometer Board R
1.1.3 & 1.4.3 1
24 ESBC025C ESBC025B Odometer Board L
1.1.3 & 1.4.3 1
71 FUS0003A FUS0003A Fuse AT blade 30A 32V
1.2.7 & 1.3 1
72 FUS0012A FUS0012A Fuse AT blade 1A 32V
1.2.7 & 1.3 1
70 FUS0015A FUS0015A Fuse mini blade 5A
1.2.7 & 1.3 1
69 FUS0021A FUS0021A Fuse 5
x
20 10A 125V
(
External Char
g
er
)
1.2.7 & 1.3 1
121 GEN0067A GEN0067A Fast char
g
er 115
/
230V
(
without cord
)
1.2.6
1 GEN0094A GEN0094A RL Yellow cover
1.1.1 1
13 GEN0095A GEN0095A RL plastic base
1.1.2 1
60 GEN0101A GEN0101A Odometer ma
g
net
1.2.5 4
39 GEN0104A GEN0104A Wheel Cup (gray)
1.2.1 2
83 GEN0116A GEN0116A Drop off fla
g
1.2.10 1
81 GEN0117A GEN0117A Ad
j
ustin
g
bolt
1.2.10 1
99 GEN0118A GEN0118A Front Wheel Click Spring ('02 configuration)
1.2.14 1
57 GEN0122A GEN0122A Shafts clamp
(
g
ear
)
1.2.5 2
64 GEN0130A GEN0130A Contact leaf-battery
1.2.6 2
63 GEN0131A GEN0131A Batter
y
Case
1.2.6 1
62 GEN0132A GEN0132A Batter
y
cover
1.2.6 1
36 GEN0133A GEN0133A Magnet for Manual Controller
1.2.1 1
34 GEN0140A GEN0140A Sealing cup
1.2.1 4
45 GEN0142A GEN0142A Connector's cover
1.2.3 1
46 GEN0145A GEN0145A Pivot for manual controller's tray
1.2.3 2
40 GEN0146A GEN0146A Main board rubber holder
1.2.2 4
97 GEN0148A GEN0148A Navigator keypad
1.2.14 1
74 GEN0156A GEN0156A Perimeter switch back cover
1.2.8 1
14 GEN0162A GEN0162A Snap lock (straight)
1.1.2 6
16 GEN0163A GEN0163A Snap lock (curved)
1.1.2 4
42 GEN0171A GEN0171A Motor shading
1.2.2 5
75 GEN0175A GEN0175A Stake for perimeter switch
1.2.8 1
51 GEN0176A GEN0176A Dockin
g
Board seal
1.2.4 1
18 GEN0182A GEN0182A Cover-base seal ring
1.2.2 1
39 GEN0201A GEN0201A Wheel Cup (black)
1.1.3 & 1.2.1 2
22 GEN0202A GEN0202A Ground clearance limiter
1.1.3 & 1.2.5 1
28 GEN0207A GEN0207A Front Wheel stopper
1.2.2 & 1.1.3 1
27 GEN0208A GEN0208A Front Wheel stopper spring
1.2.2 & 1.1.3 2
26 GEN0210A GEN0210A Charging socket rubber cover
1.2.12 1
87 GEN0211A GEN0211A Charging plug rubber cover
1.2.12 1
