1.6.2 Spare Parts – sorted by Friendly part number (con.)
#
Friendly P/N
(2006)
Friendly P/N
(2005)
Part Description
Appears in
Exploded views
No.
No. of
parts
31 GEN0215C GEN0215B Dockin
g
Station Fence
(
Green
)
1.2.4 1
54 GEN0217B GEN0217B D. Station Connectors Cover (Green)
1.2.4 3
52 GEN0218A GEN0218A Push button for Dockin
g
Board
1.2.4 1
53 GEN0223A GEN0223A Fastening Stakes for the Charging Station
1.2.4 5
1 GEN0227A GEN0227A RL Green cover
1.1.1 1
122
GEN0229A
--------
Charging Station right wheel support 1.1.4 & 1.2.4 1
123
GEN0230A
--------
Charging Station left wheel support 1.1.4 & 1.2.4 1
125
GEN0231A
--------
Gear frame support 2
85 HSN0003A HSN0003A Heat sink silicone insulator (Thermistors)
1.2.11 2
47 LMP0004A LMP0004A Operating bulb bayonet 24v/4w
1.2.3 1
73 MRK0025B MRK0025B 5 hrs. Perimeter Switch
1.2.8 1
12 MSB0065B MSB0065B Mowing Unit + cable
1.2.1 & 1.1.3 3
58 MSB0077A MSB0077A Slider assembly
1.2.5 2
3 MSB0078A MSB0078A Smooth drive wheel + bearing
1.1.1 & 1.2.1 2
59 MSB0079A MSB0079A Gear spline + bearing
1.2.5 2
78 MSB0090A MSB0090A Contact strip front assembly
1.2.8 1
79 MSB0091B MSB0091B Contact strip rear assembly
1.2.8 1
3 MSB0099A MSB0099A Knobby drive wheel + bearing
1.1.2 2
7 MSB0105B MSB0105B Man. cont. holder assembl
y
(
sp
)
1.1.1 & 1.2.3 1
10 MSB0106B MSB0106B Front bumper (one spring) assembly
1.2.8 1
5 MSB0107A MSB0107A Rear bumper assembl
y
1.2.8 1
2 MSB0112A MSB0112A Manual controller- Europe (tones)
1.1.1 & 1.2.3 1
2 MSB0114A MSB0114A Manual Controller - US
1.1.1 & 1.2.3 1
2 MSB0118A MSB0117A Manual controller (ESBC050B and forwards)
1.1.1 & 1.2.3 1
2 MSB0119A -------- Enhanced Manual Controller
1.1.1 & 1.2.3 1
84 NIT0009A NIT0009A Pop rivet/D3.2x6 (Thermistors)
1.2.11 2
114 PRG0005A PRG0005A Flash Software v3.2i
(
Service version - 03 models
)
NA
66 PWS0001A PWS0001A 230VAC power supply -Europe
1.2.6 1
66 PWS0002A PWS0002A 230VAC power supply - UK
1.2.6 1
66 PWS0003A PWS0003A 115VAC power supply - US
1.2.6 1
65 PWS0004A PWS0004A 230VAC Out Door Power Suppl
y
(
EUR
)
1.2.6 1
65 PWS0005A PWS0005A 115VAC Out Door Power Supply (US)
1.2.6 1
65 PWS0006A PWS0006A 230VAC Out Door Power Suppl
y
(
UK
)
1.2.6 1
38 RNG0002A RNG0002A Retaining ring for 12mm shaft (for Drive Wheel)
1.2.1 2
37 RNG0005A RNG0005A Spacer for Drive Wheel - D18*D12*0.5 DIN 988
1.2.1 2 to 8
80 RNG0031A RNG0030A Washer M10
x
15
(
BN 739
)
1.2.10 1
61 SCR0025A SCR0025A Screw for RL motors
1.2.5 8
50 SCR0027A SCR0027A Screw WN 1412 KA25
x
8
(
Dockin
g
Board
)
1.2.4 8
48 SCR0029A SCR0029A Screw DIN 7981C A2 4.2x25 (Docking Station)
1.2.4 5
127 SCR0033A -------- Screw for the Char
g
in
g
Station drive wheel supports
1.2.4 2
44 SPP0004C SPP0004B Spare part gear case
1.2.2 & 1.2.5 1
82 SPP0005B SPP0005B Drop off board + holder + Cable 1.2.10 1
23 SPP0008B SPP0008B Drive motor replacement kit
1.1.3 & 1.2.5 2
55 SPP0009B SPP0009A Gear Shafts replacement kit
1.2.5 1
11 SPP0011A SPP0011A Front wheel with axle
1.1.2 & 1.2.10 1
15 SPP0012A SPP0012A Sin
g
le hi
g
h cut blade
1.1.2 & 1.2.11 3
15 SPP0013A SPP0013A Sin
g
le low cut blade
1.1.2 & 1.2.11 3
20 SPP0014A SPP0014A Batter
y
contacts assembl
y
(
RL side
)
1.1.3 & 1.2.2 2
56 SPP0015A SPP0015A Gear Frame (+ GEN0202A and DOC0056A)
1.2.5 1
17 SPP0018A SPP0018A Wire Sensors x4 with cable
(
+DOC0057A
)
1.1.3 1
25 SPP0019B SPP0019B Main Board (ESBC050B)
1.1.3 & 1.4.1 1
21 SPP0020A SPP0020A Thermistors kit
1.1.3 & 1.2.11 1
9 SPP0026A SPP0026A Charging contact (for Docking Station) + screws
1.1.1 & 1.2.3 1
