1.6.2 Spare Parts – sorted by Friendly part number (con.)
#
Friendly P/N
(2006)
Friendly P/N
(2005)
Part Description
Appears in
Exploded views
No.
No. of
parts
94 SPP0027
A
SPP0027
A
Flash Software v3.2a+ (ESB0019C)
1.2.14 1
49 SPP0028B SPP0028A
Charging Station Board (includes screws, tact switch
cover and push button)
1.2.4 1
30 SPP0029A SPP0029A Charging Station Base (Yellow)
1.2.4 1
29 SPP0030A SPP0030A
Charging Station Cover (includes lexan, screws, sticker
and push button)
1.2.4 1
32 SPP0031A SPP0031A Charging Station Contacts Assembly 1.2.4 1
6 SPP0032
A
SPP0032
A
operation lamp cover + seal 1.1.1 & 1.2.3 1
115 SPP0033C SPP0033B Flash Software v3.2-06 + Operating Manual (En)
NA
115 SPP0035C SPP0035B Flash Software v3.2-06 + Operating Manual (BLX)
NA
115 SPP0036C SPP0036B Flash Software v3.2-06 + Operating Manual (DE)
NA
30 SPP0039A SPP0039A Charging Station Base (Green)
1.2.4 1
115 SPP0040C -------- Flash Software v3.2-06 + Operating Manual (IT)
NA
115 SPP0041C -------- Flash Software v3.2-06 + Operating Manual (DK)
NA
115 SPP0101A -------- Flash Software v4.1-06 + Operating Manual (En)
NA
115 SPP0102A -------- Flash Software v4.1-06 + Operating Manual (BLX)
NA
115 SPP0103A -------- Flash Software v4.1-06 + Operating Manual (DE)
NA
115 SPP0104A -------- Flash Software v4.1-06 + Operating Manual (IT)
NA
115 SPP0105A -------- Flash Software v4.1-06 + Operating Manual (DK)
NA
91 STC0012A STC0012A Rear warning sticker
1.2.13 1
89 STC0018A STC0018A Danger sticker
1.2.13 2
90 STC0022A STC0022A Front caution sticker
1.2.13 1
92 STC0036B STC0036B Battery charging decal (En)
1.2.13 1
8 STC0048A STC0048A RL550 Sticker
1.1.1 1
8 STC0049A STC0049A RL850 Sticker
1.1.1 1
8 STC0051A STC0051A RL800 Sticker
1.1.1 1
120 STC0052
A
STC0052
A
Theft Guard decal
NA
33 STC0054A STC0054A Charging station cover sticker
1.1.4 1
93 STC0055A STC0055A Charging Station fence sticker
1.2.13 1
8 STC0056A STC0056A RL1000 Sticker
1.1.1 1
8 STC0057A STC0057A RL350 Sticker
1.1.1 1
124 STC0058A ------- Crossed-out wheeled bin
1
88 TOL0001A TOL0001A Mowing motor removal tool
1.1.12 1
4 UNT0009A UNT0009A Power Pack
1.1.1 & 1.2.6 1
68 UNT0016A UNT0016A Power Pack external charging adaptor
1.2.6 1
96 WSB0025B WSB0025B Perim. wire to perim. switch cable
1.2.14 1
100 WSB0035A WSB0035A Main board to battery cable
1.4.1 & 1.5.1 1
102 WSB0041A WSB0041A Odometers cable
1.4.1 & 1.5.1 1
103 WSB0043B WSB0043B Bumper cable
1.4.1 & 1.5.1 1
105 WSB0044A WSB0044A Lamp board cable
1.2.3 & 1.5.1 1
106 WSB0046B WSB0046A Fuse holder battery pack cable
1.5.2 1
107 WSB0048B WSB0048A (-) spring battery cable
1.5.2 1
108 WSB0049B WSB0049A Battery jumper cable
1.5.2 1
101 WSB0052A WSB0052A Flat cable
1.4.1 & 1.5.1 1
98 WSB0053A WSB0053A Mowing motors cable
1.2.14 & 1.4.1 3
104 WSB0063A WSB0063A Drive motor + ferrite cable
1.4.1 & 1.5.1 1
109 WSB0070A WSB0070A Connector Board to charging contacts cable
1.5.1 1
