3.5 Skip Next Depart
Allows user to skip the next scheduled operation.
4.0 Child Guard
Child Guard is an option that allows disabling operation of the buttons of the Manual Controller
unless a pre-set two step button sequence is pressed first. While locked, the up arrow key and then
the ‘C’ key must be pressed in order to un-lock the buttons for use. Once Child Guard is ON, the
buttons will re-lock after about 60 seconds if none of the buttons were pressed. This is a very low-
level safety feature intended to prevent button use or unintended operation by very young
children. The factory default for this feature is OFF.
5.0 Safety Tests
The Safety Tests function provides a means for the customer to check the operation of the basic
safety systems of the mower. It encompasses the front wheel sensor, the front and rear bumpers
and the buttons on the Manual Controller. By entering this menu, the customer can select which
system to test and following the screen prompts, test each of the systems.
6.0 Service
The Service menu, while accessed under the User Options screen, is not a customer menu option.
It is only to be used by a trained service technician and requires a specific 5-digit code to be
entered in order to access the sub-menus.
6.1 CALIBRATIONS
6.1.1 Learn Wire Sensors
‘Learn wire sensors’ is the process of teaching the wire sensors their position relative to the
mower as well as to the signal of the perimeter wire. This process is used when the fault “Move
From Wire” is displayed, the wire sensors have been replaced and when a main board has been
replaced under a service repair.
6.1.2 Edge Calibration
Edge calibration is the process of defining how the mower will track the perimeter wire on edge
mowing. This is pre-set from the factory to basically track on center. This process would
generally be used only when a main board is replaced under a service repair or on replacement of
the wire sensors.
