6.3.10.2 Wire Sensors
In this display the LCD will display the following information:
1.Front left reading 2.Front right reading 3.Bit rate
4.Rear left reading 5.Rear right reading 6.Wire sensors state
1.Front left reading 2.Front right reading 3.Bit rate
4.Rear left reading 5.Rear right reading 6.Wire sensors state
1.Front left reading 2.Front right reading 3.Bit rate
4.Rear left reading 5.Rear right reading 6.Wire sensors state
1. Front left reading.
Front left wire sensor reading.
2. Front right reading.
Front right wire sensor reading.
3. Wire bit rate.
Indicate the frequency of the wire signal (S.W units)
4. Rear left reading.
Rear left wire sensor reading.
5. Rear right reading.
Rear right wire sensor reading.
6. Wire sensors state.
0 - all wire sensors are inside the garden
1 - forward right sensor outside the garden
2 - backward left sensor outside the garden
4 - forward left sensor outside the garden
5 - forward left and right sensors outside the garden
6 - forward left and backward left sensors outside the garden
7 - forward left forward right and backward left sensors outside the garden
8 - backward right sensor outside the garden
9 - forward right and backward right sensors outside the garden
10 - backward left and right sensors outside the garden
11 - backward left backward right and forward right sensors outside the garden
13 - forward left forward right and backward right sensors outside the garden
14 - backward left backward right and forward left sensors outside the garden
15 - all wire sensors are outside the garden
6.3.10.3 Temperature
In this display the LCD will display the following information:
1.Mow temperature (ºC) 2.Right drive temperature (ºC) 3.Ambience temperature (ºC)
4.Mow temperature (A2D) 5.Right drive temperature (A2D) 6.Charging FET temperature (ºC)
1.Mow temperature (ºC) 2.Right drive temperature (ºC) 3.Ambience temperature (ºC)
4.Mow temperature (A2D) 5.Right drive temperature (A2D) 6.Charging FET temperature (ºC)
1.Mow temperature (ºC) 2.Right drive temperature (ºC) 3.Ambience temperature (ºC)
4.Mow temperature (A2D) 5.Right drive temperature (A2D) 6.Charging FET temperature (ºC)
1. Mow temperature (ºC).
Mow temperature in ºC.
2. Right drive temperature (ºC).
Right drive temperature in ºC.
