Froling Turbomatic TMC 70 - Page 22

Installation
Assembly work
Page 22
M1020008_en s
3
U Put the front insulating cover on the side panels and push back
 Ensure that the insulating cover pin engages in the slit of the
side panels
U Screw the insulating cover to the side insulation cover plates on the
left and right
U Put on the rear insulating cover
 Ensure that the lug goes beneath the front side panel!
U Push in the bottom insulation
