(6) Modbus RTU (default address 40)
Spring balancer 0.2 - 1.5 mm
2
, cable length max. 1000 m, shielded and
twisted
(7) Temperature sensor terminal
Cable sensor PT 1000, spring balancer 0.2 - 1.5 mm
2
(8) Input - grid supply
1x 230 V or 3x 230 V, spring balancer 1.5 - 2.5 mm
2
(9) Output - L3 heating element
Spring balancer 1.5 - 2.5 mm
2
(10) Output - L2 heating element
Spring balancer 1.5 - 2.5 mm
2
(11) Multifunctional relay output
Variable max. 13 A resistive load, spring balancer 1.5 - 2.5 mm
2
WARNING!
Danger due to wires coming loose
Loose wires can come into contact with live parts and cause an electric shock.
▶
When connecting signal cables, tie the individual wires together with a cable
tie immediately before the terminal.
(12) Output - heating element / dimming level L1
Continuously variable up to 3 kW
Spring balancer 1.5 - 2.5 mm
2
