Fronius Ohmpilot - Tests and Standards Compliance

Tests/specifications
Tests/specifica-
tions
Tests/specifications per EN60730 Section 1 Table 7.2
6a Construction Electronic RS 2.5.5, independently
mounted RS
19 Screwless terminals 2.10.6.1 type X mounting
24 Classification of the RS according
to protection against electric
shock, Section 6.8
Safety class I 6.8.3
29 Type of shutdown or open circuit
for each circuit
Micro-interruption per 2.4.4.
30 PTI value of the insulation materi-
als used for insulation
PTI 175 in accordance with 6.13.2
31a Type of ground conductor connec-
tion
N in accordance with 7.4.3,
grounding terminal in accordance
with 9.1.1
39 Operating principle Operating principle TYPE 1 in ac-
cordance with 2.6.1
40 Additional properties for operating
principle
C in accordance with 6.4.3.3
51 Glow wire test temperatures (Sec-
tions 21.2.1, 21.2.2, 21.2.3 and
21.2.4)
Housing 550 °C, cable gland/
strain-relief device 650 °C; cat-
egory B in accordance with EN
60730-1:2000/A1:2004;
75 Rated surge voltage (Sections
2.1.12, 20.1)
In accordance with EN
61000-6-2:2005, EN
60730-1:2011, EN 301 489-1
(V1.9.2)
Wire to wire | Wire(s) to ground,
signal and control lines: --- ± | 1 kV
DC mains inputs: ± 0.5 kV | ± 0.5
kV
AC mains inputs: ± 1 kV |± 2 kV
77 Temperature of the ball pressure
test
In accordance with 21.2.1, 21.2.2,
21.2.3 and 21.2.4, case (housing):
Ball pressure test 1: 102°C
Cable bushing (cable gland):
Ball pressure test 2: 125 °C
80 Rated surge voltage for creepage
distance or contact-gap
In accordance with EN
61000-6-2:2005, EN
60730-1:2011, EN 301 489-1
(V1.9.2)
Wire to wire | Wire(s) to ground
Signal and control lines: --- ± | 1
kV
DC mains inputs: ± 0.5 kV | ± 0.5
kV
AC mains inputs: ± 1 kV |± 2 kV
