Technical data
Special voltages The technical data on the rating plate applies to devices designed for special voltages.
TransTig 1750
Puls
1) to public mains with 230/400 V and 50 Hz
2) d.c. = duty cycle
Mains voltage 1 x 230 V
Mains voltage tolerance -20 %/+15 %
Mains frequency 50 / 60 Hz
Mains fuse protection 16 A slow-blow
Mains connection
1)
restrictions possible
Primary continuous power (100 % d.c.
2)
) 3.8 kVA
Cos phi 0.99
Welding current range TIG 2 - 170 A
Rod electrode 10 - 140 A
Welding current at 10 min/40°C (104°F) 35%d.c.
2)
170 A
100%d.c.
2)
120 A
Open circuit voltage (pulsed) 93 V
Working voltage TIG 10.1 - 16.8 V
Rod electrode 10.3 - 25.6 V
Striking voltage U
p
9.0 kV
The arc striking voltage is designed for manual operation
Degree of protection IP 23
Type of cooling AF
Insulation class A
EMC device class
in accordance with EN/IEC 60974-10
A
Overvoltage category III
Pollution level according to IEC60664 3
Ambient temperature -10 °C - +40 °C
+14 °F - +104 °F
Storage temperature -25 °C - +55 °C
-13 °F - +131 °F
Dimensions l x w x h 430 x 180 x 280 mm
16.93 x 7.09 x 11.02 in.
Weight 9.1 kg
20.06 lb.
Marks of conformity CE
Safety symbol S
