TIG welding parameters for 2-step mode
TIG welding parameters for 4-step mode
Welding paramet-
ers in the TIG
setup 2nd
"Minimum" and "maximum" are used for setting ranges that differ according to power
source, wirefeeder, welding program, etc.
Spec. 4-step
Special 4-step mode
Unit -
Setting range OFF / 1 - 3
Factory setting OFF
1
2
3
Variant 1
Variant 2
Variant 3
Cool. unit ctrl
Cooling unit control (option)
Unit -
Setting range Aut / ON / OFF
Factory setting Aut
Aut Cooling unit is switched off 2 minutes after the end of welding
ON Cooling unit is ON all the time
OFF Cooling unit is OFF all the time
IMPORTANT! If the cooling unit is provided with the optional "thermostat", the coolant
return temperature is checked continuously. If the return temperature is less than 50
°C, the cooling unit is switched off automatically.
101
EN
