L/R alignment
L (inductivity) - welding circuit inductivity (in microhenry)
R (resistance) - welding circuit resistance (in mOhm)
See the "L/R alignment" section for further details.
Ignition time-out
Time until safety cut-out is triggered after abortive ignition attempt
Unit s
Setting range 0.1 - 9.9
Factory setting 5
IMPORTANT! "Ignition Time-Out" is a safety function so it cannot be deactivated. A
description of the ignition time out function can be found in the Chapter "TIG welding".
Arc break
Arc break watchdog
Time until safety cut-out following an arc break
Unit s
Setting range 0.1 - 9.9
Factory setting 2
IMPORTANT! The arc break watchdog is a safety function and cannot be deactivated.
A description of the arc break watchdog function can be found in the section "TIG
welding".
Ext. parameter
External parameter
a user-defined welding parameter for the JobMaster TIG welding torch or robot inter-
face (both optional).
A freely selectable welding parameter is available both on the JobMaster TIG welding
torch and for the robot interface. If "Ext. parameter" has been selected, you can use
the adjusting dial to choose between the following possibilities for this freely definable
welding parameter:
OFF No freely defined welding parameter
has been assigned (factory setting)
ELd Electrode diameter
bAL Balance
SPt Spot welding time
I-S Starting current
UPS UpSlope
I-2 Reduced current
dsl DownSlope
I-E Final current
ACF AC frequency
F-P Pulse frequency
dcY Duty cycle
I-G Base current
tAC Tacking function: Duration of
the tacking operation
Fd.1 Wire speed 1 (cold
wirefeeder option)
The number of user-defined welding parameters depends on the configuration and the
mode that has been selected.
103
EN
