9-44
E48 LED Monitor (Speed monitor item)
Data for E48
The LED monitor displays
the sub item:
0
Output frequency before slip
compensation
1
Output frequency after slip
compensation
2 Set frequency
4 Load shaft speed in r/min
5 Line speed in m/min
Selects the speed-monitoring format on the
LED
monitor.
6 Constant feeding rate time
E50 Coefficient for Speed Indication Refer to E39.
Detail for the speed display coefficient setting is given in the description of function code E39.
E52 Menu Display Mode for Keypad
Selects the menu display mode for the keypad in Programming mode.
Data for E52 The keypad will enter:
0
Function code data setting mode in which Menu #1 "Data setting" only is
displayed.
1
Function code data check mode in which Menu #2 "Data checking" only is
displayed.
2 Full-menu mode in which all menus may be displayed.
E60 Built-in Potentiometer (Function selection)
E61 Analog Input Signal Definition for [12]
E62 Analog Input Signal Definition for [C1]
E60, E61, and E62 define the function of the built-in potentiometer, terminals [12] and [C1],
respectively.
Data for E60,
E61, or E62
This function will be defined
for potentiometer and terminals [12] and [C1]:
0 None
1 Auxiliary frequency command 1*
2 Auxiliary frequency command 2**
3 PID process command 1 (J02 setting is also required.)
5 PID feedback value (Not applicable to function code E60)
* This is an auxiliary frequency input to be added to frequency command 1, but never to frequency command 2. Frequency
commands 1 and 2 are frequencies set by the means specified by F01 and C30, respectively. The set frequency can be
switched between, for example, frequency command 1 added by the auxiliary frequency and the raw frequency 2 added
by nothing, to drive the motor in the desired manner. For more details, refer to Chapter 4, Section 4.2 "Drive Frequency
Command Generator."
** An auxiliary frequency input to be added to the set frequency. For example, the auxiliary frequency input to be added to
the preset frequency used for the multistep frequency operation.
If the same data is set to these function codes, the priority order will be:
E60 > E61 > E62
